Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > CNC Fiber Laser for Cutting Sheet Metal 15030

CNC Fiber Laser for Cutting Sheet Metal 15030

Name: CNC Fiber Laser for Cutting Sheet Metal 15030
Brand: Golden Laser
SKU: 124858263
Availability: InStock

CNC Fiber Laser for Cutting Sheet Metal 15030 thumbnail-1

CNC Fiber Laser for Cutting Sheet Metal 15030 photo-1

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Laser Type:

Other, Fiber Laser, IPG Fiber laser / Coherent fiber laser

Applicable Material:

Metal

Contact Supplier Request Quote Chat Now

Wuhan Golden Laser Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai or as your requirements

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Laser Type Other, Fiber Laser, IPG Fiber laser / Coherent fiber laser

Applicable Material Metal

Cutting Thickness up to 12mm metal

Cutting Area 1500mm * 3000mm

Cutting Speed 48m/min ~ 24m/min

CNC or Not Yes

Cooling Mode Water Cooling

Control Software Golden Laser Original Software

Graphic Format Supported AI, PLT, DXF, BMP, DST, DWG, LAS, DXP

Place of Origin Hubei, China

Brand Name Golden Laser

Model Number XJG-150300DTB stainless steel cutting laser

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

Specifications

laser for cutting sheet metal
1.Fixed/Pallet Work Table
2.Open/Closed type
3.IPG/Coherent laser
4.Fiber300W 500W 1KW 2KW

CNC Fiber Laser for Cutting Sheet Metal 15030

Fiber Laser Cutting Machine for Metal ,demo video: http://youtu.be/My4cYxW_mAc

YAG Laser Cutting Machine for Metal,demo video: http://youtu.be/1v4_dPme4Y4

CO2 Laser Cutting Machine for Metal,demo video: http://youtu.be/wn6Dw37Kd74

GoldenLaser – Fiber YAG CO2 Laser Cutting Machine for Metal

Advantages Comparison between Different Types of Laser Generators:

	Fiber Laser Generator	YAG Lamp Pump Laser Generator	CO2 RF Metal Laser Tube
Power	200W~2000W	500W/650W/850W/1300W	300W/500W
Advantages	Excellent laser beam quality, high cutting precision, high cutting speed, high efficient photoelectric conversion rate, low use-cost and maintenance cost, easy operation and convenient maintenance	Compared with fiber laser generator and CO2 RF metal laser tube of the same power, it has lower price, thicker material cutting ability, wider application field and lower one-time investment.	It can cut metal sheets and non-metal materials. Wider range of applicable materials. Adjustable output power. Maintenance free. Easy to operate and convenient to use.
Applicable Materials	All kinds of metal sheets and pipes	All kinds of metal sheets and pipes	All kinds of metal sheets, acrylic, wood board and other nonmetal materials
Applicable Industry	Sheet metal, hardware, watches, metal art craft works, etc.	Sheet metal, kitchenware, metal letters and accessories & hardware, etc.	Sheet metal, advertising, furniture and models, etc.

Differnet Metal Laser MachinesPhotos

Fiber Laser Cutting Live-Action:

Fiber Laser Cutting Machine Brife Introduction:

(1) The fiber laser series are Golden Laser’s new line of metal precise processing equipment powered by fiber laser technology. The quality fiber laser beam results in faster cutting speeds and higher quality cuts compared to other cutting solutions. The key advantage of a fiber laser is its short beam wavelength (1,064nm). The wavelength, which is ten times lower than that of a conventional C02 laser, generates high absorption into metals. This makes the fiber laser become a perfect tool for cutting sheets of stainless steel, mild steel, aluminum, brass, etc.

(2)The efficiency of a fiber laser far exceeds traditional YAG or CO2 laser equipment. The fiber laser beam is capable of cutting reflective metals with much less energy as the laser is absorbed into the metal being cut. The unit will consume little to no energy when not active.

(3) Another advantage of fiber laser is the use of highly reliable single emitter diodes with projected lifetimes greater than 100,000 hours of continuous or pulsed operation.

(4) Golden Laser software allows for the capability to control power, modulation rate, pulse width and pulse shape giving the user full control of the lasers capabilities.

Fiber Laser Cutting Advantages:

·Long lifespan(100,000 hours)of the laser module(IPG laser source 300W, 500W, 1000W and 2000W for choice)

·Specialish for thin Sheet in Precision

·Auto focus system to change focus length automatically while process uneven materials

·Nesting Software provides efficiency and saving materials

·Minimized burrs and roughness

·Lowest maintenance cost and power consumption·Easy operation

XJG-150300JH fiber laser cutting machine for metal

Fiber Laser Cutting Machine Features:

♦The double ball screw closed-loop system and imported open-type CNC system enable high processing accuracy and high working efficiency during high speed cutting.

♦Standard collocation of 1000W fiber laser generator and optional 300W-2000W fiber laser generator ensures low operation and maintenance cost.

♦Enclosure design meets CE standard, reliable and safe processing. Shuttle table/pallet working tables convenient for material uploading and unloading and further promotes working efficiency.

♦Aiming at high speed cutting, we design and manufacture strengthened welded machine body after 2 times of aging process which ensures long-term accuracy and stability of performance.

♦Standard collocation of dual-pressure gas control system of 3 gas sources (high pressure air, nitrogen, oxygen) meets the processing requirement of all kinds of materials. Easy operation and low cost.

♦Standard collocation of automatic nesting software (including material management and optimized processing technology) and database of process parameters is provided for easy operation and simple management.

♦Optimized optical lens, specially designed nozzle and sensor technology realize smoother and more stable cutting.

XJG-150300JH / XJG-150300DTB Fiber Laser Cutting Machine Main Technical Data
Laser Type:	IPG Fiber laser / Coherent fiber laser
Laser Power:	500W / 300W / 1000W / 2000W
Working area:	1500mmX3000mm / 2000mmX4000mm / 2000mmmX6000mm
Working Table Structure:	Fixed / Pallet Working Table
Control System:	PMAC full-closed loop servo control
Driving Mode:	Double ball screw driving / Double gear rack driving
Idle/Processing Speed:	48m/min / 24m/min
Positioning Accuracy:	0.05mm
Cooling System:	High precision constant temperature water chiller
Protection System:	Enclosure protection
Laser Head:	Golden Laser / Precitec / Laser mech
Power Supply:	AC220V ± 5% 50 / 60Hz / AC380V ± 5% 50 / 60Hz
Total Power:	7.5KW / 6KW~20KW
Support Format:	PLT, DXF, BMP, AI, DST, DWG, etc.
Floor Space:	5.8m X 3.3m
Other Standard Collocation:	Metal nesting software, dual-pressure gas route of 3 kind gas sources, dynamic focus, remote controller, etc.
Related Model:
XJG-6040 DT	Fiber Laser Cutting Machine 600X400mm
XJG-13090 DT	Fiber Laser Cutting Machine 1300X900mm
XJG-150300 DT	Fiber Laser Cutting Machine 1500X3000mm
GJMSJG-Series	YAG Laser Cutting Machine 600X400mm,1300X900mm,1300X2500mm,1500X3000mm

Applications

Applicable Materials:

Laser cutting stainless steel, mild steel, carbon steel, alloy steel, spring steel, iron, galvanized iron, galvanized sheet, aluminum, copper, brass, bronze, gold, silver, titanium plates, metal sheets, metal plates, metal tubes and pipes. Cut the shape of Circle, Triangle, Octagonal and so on

Applicable Industries:

laser cutting machines have been widely used in manufacture billboard, advertising, signs, signage, metal letters, LED letters, advertising letters, sheet metal processing, metals components and parts, ironware, chassis, racks & cabinets processing, kitchen ware, metal crafts, metal art ware, elevator panel cutting, hardware, auto parts, jewelry, glasses frame, nameplates, electronic parts, etc.

Fiber Laser Cutting Metal Samples
