CE APPROVED Self-propelled Shot Blasting Machine
- 50 Set / Sets per Month
- Qingdao
- T/T
- Supports multi-hook customization of Pumingwei hook-type shot blasting machine surface metal rust removal equipment
- tumble rubber belt shot blasting machine for foundry plant crawler shot blaster
- smaller casting parts surface treatment crawler shot blasting machine
- Q326 Q324 Q3210 tumble belt shot blasting machine crawler belt shot blasting machine
- Tumble belt shot blasting machine for nuts and bolts surface treatment
- Tumbler belt shot blasting abrator machine wheel crawler shot blaster
Product Details
Condition: | New | Place of Origin: | Shandong, China | Brand Name: | HESONG |
Model Number: | Q6910 | Feature: | Critical Cleaning / Residue Free, Non-Ionic, Non-Toxic, Rust / Corrosion Inhibitor, Sudsing / Foaming, Rust / Corrosion Inhibitor | Fuel: | Electric |
Certification: | CE, Other, CE, ISO9001 | Use: | Burnishing, Container / Bottle Cleaning, Deflashing, Degreasing, Descaling / Stripping, Sterilizing / Disinfecting | Cleaning Process: | Other, STEEL SHOT |
Cleaning Type: | Other, SHOT BLASTING | Industry Used: | Other, STEEL INDUSTRY, Construction, shipping build,bridging industry | Material: | Metal / Coil |
Power(W): | Self-propelled Shot Blasting Machine | Dimension(L*W*H): | Self-propelled Shot Blasting Machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Self-propelled Shot Blasting Machine
Application of Steel Plate Self-propelled Shot Blasting Machine :
Roller Conveyor Type Shot Blasting Machine is available for a wide variety of steel products, such as steel plates, sheets, strips, wires, bars, billets, slabs, rolled and fabricated structural shapes, and miscellaneous weldments, pipe, tubing and gas cylinders.
Main components of Steel Plate Self-propelled Shot Blasting Machine :
1. Inlet roller
2. Shot blasting chamber
3. Sweeping chamber
4. Abrasive/ shot balls circulation system
5. Shot cycle purifying system
6. Shot dust collecting system
7.Fume filter and harmful gas purifying device
8.Outlet roller
9.Electric control system
Features of Steel Plate Self-propelled Shot Blasting Machine :
1. Roller Conveyor Type Shot Blasting Machine is designed for the large, middle and small size of the steel products.
2.Using the highest efficiency blast wheels and adopt Multi-dimensional blasting, high-level and all- directional clean.
3. Cleaning away the rusting layer, oxidation layer and other dirty things from steel surface
4.To make surface achieve a bright and clean surface and improve the adhesion force of painting to surface and improve the anti-fatigue force and anti-rust capacity.
1. Steel Plate Shot Blasting Machine and H Beam Shot Blasting Machine
Technical parameter of Roller Conveyor Type Shot Blasting Machine | |||||||||
No. | Model | Q698 | Q6912 | Q6915 | Q6920 | Q6925 | Q6930 | Q6940 | |
1 | Width of workpiece | mm | 800 | 1200 | 1500 | 2000 | 2500 | 3000 | 4000 |
2 | Size of inlet opening | mm | 800* | 1200* | 1500* | 2000* | 2500*800 | 3000*800 | 4000*400 |
3 | Length of workpiece | mm | 1200- | 1200- | 1200- | 1200- | 3000-12000 | 2400-12000 | 4500-18000 |
4 | Roller speed | m/min | 0.5-4 | 0.5-4 | 0.5-5 | 0.5-4 | 0.5-4.5 | 0.5-4 | 2-8 |
5 | Thickness of plate | mm | 3-60 | 3-60 | 1.5-60 | 3-60 | 3-60 | 3-110 | 4.5-110 |
6 | Abrasive flow rate | kg/min | 8*120 | 4*250 | 4*250 | 6*250 | 6*250 | 6*360 | 8*360 |
7 | Abrasive initial fill | kg | 4000 | 4000 | 4000 | 4500 | 4500 | 8000 | 11000 |
8 | Adjusting height of rolling brush | mm | 400 | 200 | 350 | 450 | 600 | 850 | 900 |
9 | Ventilation capacity | m3/h | 22000 | 17560 | 19000 | 19550 | 27758 | 28050 | 38000 |
10 | Total power of shot blast machine | kw | 90 | 78.3 | 113.6 | 156.6 | 224.55 | 204.8 | 293.6 |
2. Steel Pipe Shot Blasting Machine
QG Series Steel Pipe Wheel Blast Machine is suitable for the surface treatment of steel pipe and related products, wiping up the oxide coating, welding slag to make the surface appear metallic sheen, increasing the surface area. It is widely applied in the industries, such as petroleum & chemical, steel, city centralized heating, centralized drainage, etc.
Shot Blasting Machine is often used for:
Cleaning
Deflashing
Rust and Scale Removal
Anchor Pattern Creation
Peening
Coating Removal
The examine goods in our factory :
Why choose us ?
1. Our company has passed "CE", "ISO9001" and bureau veritas certification .
2. 50 years experience with 20 professional engineers in our Qingdao Foundry Machine Co.,Ltd.
3. So many kinds of foundry machinery ---100 kinds of shot / sand blasting machines and 80 kinds of casting machines.
4. Considerate after-sale service , Technial Assistance and provide installing ,debugging and training on site
5. The company has its own foreign trade marketing team Industrial Corporation, first - class service standards for all clients.
Qingdao Foundry Machinery Co.,LTD,established in Oct.1994,is located in Qingdao city,We own over 50,000 square metres factory,25,000 square metres workshop,about 850 workforce and 100 engineers and technicians.
We have advanced equipment and technology and professional team and we has got ISO9001 and CE certificate.
Our certification
We specialize in the design and manufacture of:
Shot Blasting Machine
Sand Blasting Machine and manual sandblasting pot
Foundry sand mixer
Core shooter
Jolt Squeeze Molding Machine
Sand preparation line for foundry (Clay and resin sand )
Automatic Moulding Machine(line)
The key part of shot blasting machine is blast wheel / wheel turbine :
We are factory for manufacturing alll kinds of foundry machinery and almost spare parts, We have special spare part depart.
We offer a full maintenance service! Manufacturers can provide repair facilities for consumers and to stock adequate spare parts so repairs can be undertaken. Tel (400-1177-399)
Testing machine for shot blasting machine
With instruments, metalworking, grinder, rolling wire four workshops, complete production facilities.
There are many kinds of Shot Blasting Machines as follows:
Q69 Series Roller Conveyor Type Shot Blasting Machine
KSB Series Hook Type Shot Blasting Machine
Q37 Series Shot Blasting Machine For Engineering Machinery
Q311 Series Drum Type Shot Blasting Machine
Q26/Q36 Series Flatcar Shot (Spray) Type Cleaning Machine
Q76 Series Trolley Type Shot Blasting Machine
Q38 Continuous Pendant Chain Type Shot Blasting Machine
Q48 Step-By-Step Pendant Chain Type Shot Blasting Machine
Q58 Changeable Chain Type Shot Blasting Machine
ZJ0 Series Rotary Table Shot Blasting Machine
ZJ02 Series Spring Shot Blasting Machine
ZJ18 Series Wheel Roller Shot Blasting Machine
QGW Series Steel Tube Outer Wall Shot Blasting Machine
QGN Series Pipe Inwall Shot Blasting Machine
GN Series Belt Type Shot Blasting Machine
Q32 Series Apron Type Shot Blasting Machine
Q35 Series Turntable Type Shot Blasting Machine
QWD Series Wire Mesh Belt Type Shot Blasting Machine
QSHBSeries Rotary Hook Type Shot Blasting Machine
QX Series Wire Rod Shot Blasting Machine
QM Series Special Shot Blasting Machine For Anchor Chain
RE Series Shot Peening Machine For Strengthening For Mill Roll
CND Series Inclined Drum Shot Blasting Machine
SHB Series Turntable Shot Blasting Machine
Ql Series Squirrel-Cage Type Shot Blasting Machine
ZJ076 Series Leaf Spring Shot Peening Machine For Strengthening
SCC Series Spring Shot Peening Machine For Strengthening
SNC Series Bar Shot Blasting Machine
In order to give you the suitable machine , pls provide below message for us :
1. What is your workpiece and the material and the shape ?
2.The Max. Length/Width/Height of the workpiece and the MAX./MIN.weight of your workpiece ?
3.The productity you need to blasting the workpiece ( how many T or piece per day or per month?)
4. The power supply you need( Our China :380V, 3PH, 50HZ)
5. Better to send us the workpiece photo or drawing.
Welcome to contact us or visit our company.
Contact Information:
Ms. Bonnie Peng
Skype: castingglobal
QQ: 1154609933
SHOT BLASTING MACHINE Appliation :
1.Agriculture industry
Shot blasting:tractor components,water pumps,farm implements,etc.
2.Automobile industry
Shot blasting:engine blocks,cylinder heads,break drums,etc.
3.Building & infrastructure industry
Shot blasting:structural steel,bars,transmission & television towers,etc.
4.Transportation industry
Shot blasting:engine blocks,axle & crank shafts,diesel engine components,etc.
5.Oil & gas industry
Surface preparation:pipes coating with paper,cement,epoxy,polythene,coal tar,etc.
6.Mining industry
Shot blasting:bulldozer,dumpers,crushers,land fill equipments,etc.
7.Foundry industry
Shot blasting:automobile,tractor,scooter & motor cycle components,etc.
8.Aluminum casting industry
Shot peening:automobile,scooter & motor cycle components,etc.
9.Forging industry
Shot blasting:crank shafts,connecting rods,torsion bars,other forged components,etc.
10.Railway industry
Shot blasting:side frames,bolster,couplers,rail wheel,entire coach,etc.
11.Electrical industry
Shot blasting:motor body,transformer tank,transmission tower,etc.
12.Energy & power industry
Shot blasting:sturbines,boilers,switch gear components,wind mill blades,column,etc.
13.Stainless steel industry
Shot blasting:strips,angles,channels,pipes,tee,etc.
14.Aviation industry
Shot peening:jet engine,blades,propeller,turbine,hubs,land gear components,etc.
15.Shipyard industry
Shot blasting:steel plates,angles,channels,beams,etc.
16.Steel mill industry
Shot blasting:strips,angles,channels,pipes,tee,etc.
17.Air polution control equipments
Applications:foundry,carbon black,furnace,cupola,etc.
18.Ceramic/paver industry
Applications:antiskid,footpath,hospital,government buildig,public places,etc.
