Wire mesh welding machine (hot sale)
- 10 Set / Sets per Month
- TIANJIN
- T/T
- Spot welder welding machine vertical Point Welded Wire Mesh Machine
- Pneumatic automatic diameter feeder, automatic net discharge and net falling, reinforced mesh welding machine
- Pneumatic hanging wire automatic feeding diameter automatic net turning and netting steel mesh welding machine
- Pneumatic hanging wire automatic net out and net down mesh welding machine for reinforced mesh
- Mechanical automatic diameter feeding, automatic net out and net falling, reinforced mesh welding machine
- Mechanical wire hanging, automatic diameter feeding, automatic net turning and netting, reinforced mesh welding machine
Product Details
Condition: | New | Place of Origin: | Hebei, China | Brand Name: | DAPU |
Model Number: | DP-MW-1200 | Usage: | Wire mesh welding machine (hot sale) | Voltage: | According to clients' voltage |
Current: | 80A | Rated Duty Cycle: | 50% | Rated Capacity: | 56KVA*3PCS |
Dimensions: | 2.5*2/1*1.4m | Weight: | 2.5T | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Wire mesh welding machine (hot sale)1.Wire diameter:1.4-2.5mm;2.5-3.5mm
2.Mesh width:1.2m2.5m
3.Factory in Anping,Hebei
Wire mesh welding machine (hot sale)
Wire mesh welding machine (hot sale)
Wire mesh welding machine (hot sale)
Wire mesh welding machine (hot sale)
Type | DP-MW-1200A | DP-MW-1200B | DP-MW-1200C |
Wire Diameter | 1.4-2.5mm | 2.5-3.5mm | 3-5mm |
Longitude Wire Space | 50-200mm | 50-200mm | 50-200mm |
Cross Wire Space | 25-200mm | 25-200mm | 50-200mm |
Width of Mesh | 1200mm | 1200mm | Max 2500mm |
Welding Electrodes | 25pcs | 25pcs | 48pcs |
Welding Speed | 60 times/min | 45 times/min | 45 times/min |
Longitude Wire Feeding | From Wire Coils | From Wire Coils | From Wire Coils |
Cross Wire Feeding | From Wire Coils | Pre-cut&Straightened | Pre-cut&Straightened |
Rated Electrical Power | 56kva*3pcs | 85kva*3pcs | 100kva*6pcs |
Wire mesh welding machine (hot sale)
