Border Fencing Security Concertina Barbed Wire Machine

Border Fencing Security Concertina Barbed Wire Machine thumbnail-1
Border Fencing Security Concertina Barbed Wire Machine thumbnail-2
Border Fencing Security Concertina Barbed Wire Machine thumbnail-3
Border Fencing Security Concertina Barbed Wire Machine thumbnail-4
Border Fencing Security Concertina Barbed Wire Machine thumbnail-5
Border Fencing Security Concertina Barbed Wire Machine thumbnail-6
Border Fencing Security Concertina Barbed Wire Machine photo-1
Border Fencing Security Concertina Barbed Wire Machine photo-2
Border Fencing Security Concertina Barbed Wire Machine photo-3
Border Fencing Security Concertina Barbed Wire Machine photo-4
Border Fencing Security Concertina Barbed Wire Machine photo-5
Border Fencing Security Concertina Barbed Wire Machine photo-6
US$ 6,700 - 6,700 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
DAPU
Model Number:
Rm2
Contact Supplier Request Quote Chat Now
Hebei Dapu Import & Export Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang Port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hebei, China
Brand Name DAPU
Model Number Rm2
After-sales Service Provided Engineers available to service machinery overseas

Border Fencing Security concertina barbed wire machine

Border Fencing Security concertina barbed wire machine

Product Description

 Structure: razor strip making machine, coiling machine

Function:

Razor strip making machine cuts steel strip into different razor shapes according to different moulds.

Coil machine wraps razor strip up onto the steel wire and wind up the finished products into rolls.

Application

Razor barbed wire is extensively used for security isolation of military facilities, communication stations, power distribution stations, border prisons, landfill, community protection, schools, factories, farms, etc.

Technical parameter

Punching machine

Model

Five strip

Voltage

380V, 50Hz or client’s required voltage

Power

2.2kw

Producing speed

220-280m/h

Thickness

0.5±0.05mm

Pressure

25T

Weight

1500Kg

Dimension

1200mm×1000mm×1900mm

Coiling machine

Voltage

380V, 50Hz,or client’s required voltage

Power

1.5kw

Producing speed

80Kg/h

Wire diameter

2.5mm

Weight

300Kg

Dimension

1100mm×750mm×1200mm

Mould

Mould type

Barb Length

Barb width

Barb spacing

R1

12±1mm

13±1mm

26±1mm

R2

12±1mm

15±1mm

26±1mm

R3

18±1mm

15±1mm

33±1mm

R4

22±1mm

15±1mm

34±1mm

R5

28±1mm

15±1mm

34±1mm

R6

30±1mm

18±1mm

34±1mm

R7

60±1mm

32±1mm

96±1mm

R8

65±1mm

21±1mm

100±1mm

Barbed wire machine price

Border Fencing Security concertina barbed wire machine   Border Fencing Security concertina barbed wire machine

Suitable material: galvanized wire.

Model

 CS-A

CS-B

CS-C

Motor power (KW)

 2.2

2.2

2.2

Main drive shaft speed (r/min)

 402

355

355

Wire Diameter (mm)

 2.2-3

2.2-3

1.6-2.8

Barbed wire diameter (mm)

 1.8-2.2

1.8-2.2

1.6-2.2

Barbed space (mm)

 76mm/102mm/127mm

102mm/127mm

102 (34 Inch)/ 127 (5 Inch)

Twisted number

 3-5


9

Theoretical production (kg/h)

 70

40

40

Total weight (kg)

 1050


1000

Dimension (L×W×H)(mm)

1950*950*1300

1760*550*760

3100×1000×1150

3100×1000×1150


Advantages

1. saves time, 20% raw materials and cost.

2. easy operation,

3. high efficiency,

4. easy maintenance and material saving.

Photos Display

Punching machine

Border Fencing Security concertina barbed wire machine   Border Fencing Security concertina barbed wire machineBorder Fencing Security concertina barbed wire machine   Border Fencing Security concertina barbed wire machine

Coiling machine

Border Fencing Security concertina barbed wire machine   Border Fencing Security concertina barbed wire machine

Moulds

Border Fencing Security concertina barbed wire machine

Finished products

Border Fencing Security concertina barbed wire machine     Border Fencing Security concertina barbed wire machine

Certifications

Importantly, our machinery approved ISO9001 certification and CE Certificate in 2006 and 2009 successively .Border Fencing Security concertina barbed wire machine

Factory

Border Fencing Security concertina barbed wire machine

Company Information

Product Catelogue

nail making machine                                      chain link fence machine
wire drawing machine                                    crimped mesh machine
wire straightening & cutting machine            grassland fence machine
steel fiber machine                                          expanded metal mesh machine
barbed wire machine                                      hexagonal wire netting machine
razor barbed wire machine
gabion mesh machine(chicken cage machine/ stone cage mesh machine)
Our Services

1.      Guarantee period: 12 months (but no longer than 18 months since departure from Xingang Port).

2.      Customized machine.

3.      OEM support.

4.      Fast delivery.

5.      Moderate price.

6.      Door to Door service or 24-hour email service.

Our engineers are available to install and maintain machine overseas.Border Fencing Security concertina barbed wire machine
