Concrete floor Wheel Blasting machine
Our factory covers an area of 26000 square meters. We have about 260 employees including more than 50 middle and senior technical staff.
Professional software such as Auto CAD and Solid works have been used to provide exact drawings. SAP, Office Automation system been used to control and smooth the work flow.
We have a Quality Inspection Center with Dynamic balance detector, Static balance tester and other advanced equipments to detect finished products, which can guarantee the quality of each product.
All the products are designed by our technical department and tested by our own quality supervise department. We have the ISO9001 International Certification and CE Certification.
1.Application of Concrete floor Wheel Blasting machine :
• Concrete floor Wheel Blasting machine is designed for clean airport runways
• Concrete floor Wheel Blasting machine cleans factory and warehouse floors and other floors.
• Concrete floor Wheel Blasting machine prepares concrete for recoating or application of overlays
• Concrete floor Wheel Blasting machine removes marking, dirt and old coatings
• Concrete floor Wheel Blasting machine is used on bridge decks and highways
• Concrete floor Wheel Blasting machine stencil patterns for decorative concrete applications
• Concrete floor Wheel Blasting machine prepares parking lots and garage decks
Concrete floor Wheel Blasting machine
Blasting width |
270mm |
|
Blasting capacity |
Up to 150m²/h on concrete |
|
Motor |
11kW / 380V - 50Hz / 32A - Three phases |
|
Dimensions(LxWxH) |
1940mm X 380mm X1100mm |
|
Drive system/Speed |
Electric /0.5-25m/min |
|
Mode of operation |
Horizontal movable self-propelled Backward(pull) |
|
Surface |
Steel/Concrete/Stone/Asphalt |
|
Accessories | ||
Suction hose |
Diameter150mm X Length20m |
|
Dust collector |
Motor |
7kw |
Airflow |
1250m³/h |
|
Dimensions(LxWxH) |
2030mmX870mmX1500mm |
|
Blasting width |
550mm |
|
Blasting capacity |
Up to 300m²/h on concrete |
|
Motor |
2x11kW / 380V - 50Hz / 63A - Three phases |
|
Dimensions(LxWxH) |
1950mm X 720mm X1400mm |
|
Drive system/Speed |
Electric /0.5-25m/min |
|
Mode of operation |
Horizontal movable self-propelled Backward(pull) |
|
Surface |
Steel/Concrete/Stone/Asphalt |
|
Accessories | ||
Suction hose |
Diameter150mm X Length20m |
|
Dust collector |
Motor |
7kw |
Airflow |
1250m³/h |
|
Dimensions(LxWxH) |
2030mmX870mmX1500mm |
|
Small-sized machine will be pakced by wooden box
Medium-sized machine will be no bulk and load into container directly
Large-sized machine will be load into special container ( skeletal container or open top, flat and platform containers)
We are factory for manufacturing alll kinds of foundry machinery and almost spare parts, We have special spare part depart.
We offer a full maintenance service! Manufacturers can provide repair facilities for consumers and to stock adequate spare parts so repairs can be undertaken. Tel (400-1177-399)
Our machine had approved CE AND ISO AND BV , SO OUR MACHINE CAN EXPORT TO ALL COUNTRIES.
SHOT BLASTING MACHINE Appliation :
1.Agriculture industry
Shot blasting:tractor components,water pumps,farm implements,etc.
2.Automobile industry
Shot blasting:engine blocks,cylinder heads,break drums,etc.
3.Building & infrastructure industry
Shot blasting:structural steel,bars,transmission & television towers,etc.
4.Transportation industry
Shot blasting:engine blocks,axle & crank shafts,diesel engine components,etc.
5.Oil & gas industry
Surface preparation:pipes coating with paper,cement,epoxy,polythene,coal tar,etc.
6.Mining industry
Shot blasting:bulldozer,dumpers,crushers,land fill equipments,etc.
7.Foundry industry
Shot blasting:automobile,tractor,scooter & motor cycle components,etc.
8.Aluminum casting industry
Shot peening:automobile,scooter & motor cycle components,etc.
9.Forging industry
Shot blasting:crank shafts,connecting rods,torsion bars,other forged components,etc.
10.Railway industry
Shot blasting:side frames,bolster,couplers,rail wheel,entire coach,etc.
11.Electrical industry
Shot blasting:motor body,transformer tank,transmission tower,etc.
12.Energy & power industry
Shot blasting:sturbines,boilers,switch gear components,wind mill blades,column,etc.
13.Stainless steel industry
Shot blasting:strips,angles,channels,pipes,tee,etc.
14.Aviation industry
Shot peening:jet engine,blades,propeller,turbine,hubs,land gear components,etc.
15.Shipyard industry
Shot blasting:steel plates,angles,channels,beams,etc.
16.Steel mill industry
Shot blasting:strips,angles,channels,pipes,tee,etc.
17.Air polution control equipments
Applications:foundry,carbon black,furnace,cupola,etc.
18.Ceramic/paver industry
Applications:antiskid,footpath,hospital,government buildig,public places,etc.
In order to give you the suitable machine , pls provide below message for us :
1. What is your workpiece and the material and the shape ?
2.The Max. Length/Width/Height of the workpiece and the Max./Min.weight of your workpiece ?
3.The productity you need to blasting the workpiece ( how many T or piece per day or per month?)
4. The power supply you need( Our China :380V, 3PH, 50HZ)
5. Better to send us the workpiece photo or drawing.
Welcome to contact us or visit our company.
There are some founday machinery -----sand molding machine and sand core shooter machines.
There are some shot blasting machines for cleaning pipe , tube, casting parts and soon on.
There are some sandblasting pot and chamber at our factory
