Specifications
1.High conversion efficiency
2.Superior quality
3.Lowest price
4.Certificate:CE,SGS,ISO,TUV,UL.
5.Prompt delivery
Dimensions |
156mm x 156mm ± 0.5mm |
Thickness(Si) |
180μm ± 20μm / 200μm ± 20μm |
| Front | Silver bus bars; Blue/Purple |
Silicon nitride anti-reflection coating | |
| Back | Silver bus bars; Full-surface aluminum BSF |
2.5mm (silver / aluminum) discontinuous soldering pads |
Efficiency code |
Efficiency(min) (%) |
Charged power(WP) |
Imp(A) |
Vmp(V) |
Isc(A) |
Voc(V) |
| 2060 | 20.60 | 4.92 | 8.90 | 0.553 | 9.43 |
0.659 |
| 2050 | 20.50 | 4.90 | 8.88 | 0.552 | 9.42 |
0.658 |
| 2040 | 20.40 | 4.88 | 8.86 | 0.550 | 9.41 |
0.657 |
| 2030 | 20.30 | 4.85 | 8.84 | 0.549 | 9.40 |
0.656 |
| 2020 | 20.20 | 4.83 | 8.82 | 0.548 | 9.39 |
0.655 |
| 2010 | 20.10 | 4.80 | 8.81 | 0.547 | 9.38 |
0.654 |
| 2000 | 20.00 | 4.78 | 8.79 | 0.545 | 9.37 |
0.653 |
| 1990 | 19.90 | 4.76 | 8.76 | 0.544 | 9.34 |
0.652 |
| 1980 | 19.80 | 4.73 | 8.74 | 0.543 | 9.32 |
0.651 |
| 1970 | 19.70 | 4.71 | 8.72 | 0.542 | 9.31 |
0.649 |
| 1960 | 19.60 | 4.68 | 8.71 | 0.540 | 9.30 |
0.647 |
|
|
|
|
|
1.What is the business type for the company?
We are manufacturer, making poly and mono solar cell, welcome to vist our factory.
2.What is the brand for this panel?
XXsolar,OEM high efficiency solar cell service is available, wholesales is welcome.
3:How long solar cell warranty can you offer?
10 Years product warranty. degradation:12 years reduce 10%, 25 years reduce 20%,
4.Can I be the agent for you?
Yes,We will discuss condition in detail.
5.Can i buy a high efficiency solar cell sample for testing performance?
yes,our MOQ is one piece
