Home > Products > Incoloy 800H > Nickel Alloy Incoloy 800H Sheet N08810
Nickel Alloy Incoloy 800H Sheet N08810
- Shanghai
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | China | Type | Nickel Plate | |
| Application | chemical processing, pollution-control equipment.oil and gas | Grade | Incoloy 800H UNS N08810 | |
| Ni (Min) | 30 | Powder Or Not | Not Powder | |
| Model Number | Incoloy 800H UNS N08810 | Brand Name | Longxin alloy |
Product Description
Nickel alloy incoloy 800H sheet N08810
Incoloy 800H Chemical composition
Grade | % | Ni | Cr | Fe | C | Mn | Si | Cu | S | Al | Ti |
800 | Min | 30 | 19 |
Bal |
|
|
|
|
| 0.15 | 0.15 |
Max | 35 | 23 | 0.10 | 1.5 | 1 | 0.75 | 0.015 | 0.60 | 0.60 | ||
| 800H | Min | 30 | 19 | Bal | 0.05 | 0.15 | 0.15 | ||||
| Max | 35 | 23 | 0.10 | 1.5 | 1 | 0.75 | 0.015 | 0.60 | 0.60 | ||
| 800HT | Min | 30 | 19 | Bal | 0.06 | 0.15 | 0.15 | ||||
| Max | 35 | 23 | 0.10 | 1.5 | 1 | 0.75 | 0.015 | 0.60 | 0.60 | ||
| Al+Ti:0.85-1.20 | |||||||||||
Incoloy 800H Physical Properties
Density | 8.0g/cm3 |
Melting point | 1350-1400℃ |
Minimum in the room temperature mechanical properties of Incoloy 800H
Alloy | Tensile Strength Rm N/mm2 | Yield Strength RP0.2N/mm | Elongation σ5 /% |
| 800 | 500 | 210 | 35 |
| 800H | 450 | 180 | 35 |
Incoloy 800H alloy has the following features:
1. having excellent corrosion resistance at a very high temperature up to 500 ℃ aqueous medium
2. good Resistance to stress corrosion performance
3. good workability
Incoloy 800H metallurgical structure:
800H for the face-centered cubic lattice structure. Very low carbon content and improving the Ti: C ratio increases the stability and structure of the largest anti-allergy activity and resistance to intergranular corrosion. Low temperature annealing around 950 ℃ guaranteed fine grain structure.
Incoloy 800H corrosion resistance:
Many corrosive media capability 800H corrosion. Its high nickel content in aqueous corrosion conditions has good resistance to stress corrosion cracking. High chromium content so that it has better resistance to pitting and crevice corrosion cracking. The alloy has good resistance to nitric acid, organic acid corrosion, but limited corrosion resistance in sulfuric acid and hydrochloric acid. In addition to pitting corrosion may occur halide, there are very good corrosion resistance in oxidizing and non-oxidizing salt. Water, steam and mixtures of steam, air, carbon dioxide also has good corrosion resistance.
Incoloy 800H Application field are:
1. Condenser nitrate - nitric acid corrosion resistance
2. Steam heating pipes - very good mechanical properties
3. The heating element tube - very good mechanical properties
For applications up to 500 ℃ environment state is annealed alloy supplier.
