Trailer Type Diesel Generator
- 8000 Set / Sets per Month
- Qingdao China
- T/T
Product Details
Place of Origin: | Shandong, China | Brand Name: | U-POWER | Output Type: | AC Three Phase |
Speed: | 1500rpm/1800rpm | Frequency: | 50Hz/60Hz | Rated Voltage: | 400v/230v |
Product Description
Specifications
Trailer Diesel Generator1)Cannopy and trailor,
2)Powered by Ricardo
3)Weichai diesel engines
4)Water Cooled
Diesel generator set
Specifications: Selected Sample 1
1) Output range: 1,00kW (1,25kVA)
2) Engine model: UP6105IZLD
3) Alternator model: GM / MP
4) Water-cooled
5) 8hrs operation base tank
6) Key start / auto start
7) Sound-proof / weather-proof canopy is optional
8) 230 / 400V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires
alternating current output
9) Frequency: <3%
10) Frequency at stable state: <0.5%
11) Frequency deviation at instantaneous state: ≤+10%
12) Frequency return time: ≤3s
13) Voltage deviation at stable state: ≤±1%
14) Voltage deviation at instantaneous state: ≤+20%
15) Voltage return time: ≤4s
16) Voltage modulation: ≤0.3%
17) Standard configuration of gensets:
a) Engine: U-Power6105IZLD diesel engine
b) Engine type: water-cooled, in line four-stoke, Humit cylinder liner,
direct injection
c) Alternator: Marathon brushless alternator
18) Control system:
a) Automatic alarm system: the unit has the acousto-optics alarm
system and arrestor for any situation as the start defeat, the water
is over temperature, the oil pulls down, over speed, over load and
over current
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers
19) Starting system: DC alternator is used to start engine
Reference Picture:
