Help Center20kw Deutz Diesel Generator Set
Related Products
-
Canopy Diesel Generator SetUS$ 2,000 - 20,000MOQ: 120 Sets -
Diesel Engine Generator Set Deutz/styerUS$ 2,000 - 20,000MOQ: 1 Set
-
Silent Generator Set Powered by DeutzUS$ 2,000 - 20,000MOQ: 1 Set
-
75kw Diesel Generating Set Powered by RicardoNegotiableMOQ: 1 Set
-
Silent Diesel Generator Set Closd ShelterUS$ 1,400 - 25,000MOQ: 1 Set
Specifications
Deutz Diesel Generator1)Stable performance
2)Energy saving diesel engine
3)High Efficient generator
4)Remote CTRL:Optional
Brief Introduction: Deutz D226B series Land use
1) Prime output: 20-120KW/25-150KVA
2) Max output: 22-132KW/27.5-165KVA
U-POWER Deutz D226B Series generating set matched D226B series engines made by Sino-Germany Venture—Weichai Power Co..LTD.The alternators are world famous brands, Stamford,Marathon,Leory Somer or China alternators.There are optional equipments as listed bottom.
Selected Program:
1) Prime output: 50KW/62.5KVA
Diesel Engine:
1) Engine model: TD226B-4D
Cyliner Nos.: 4
Bore/stroke: 105/120mm
Rated power: 45kw
2) Cooling method: closed Water-cooled
3) Start method: Electrical
4) Speed governing: Mechanical/Electronic(Optional)
5) Intake method: Turbocharged
Alternator:
1) Alternator model: Stamford / Marathon/Landian/Qianghui/China alternator
Rated power: 40kw
2) 400 / 230V AC, 50Hz / 60Hz, 0.8pF three-phase and four wires
3) Frequency: <3%
4) Frequency at stable state: <1.0%
5) Frequency deviation at instantaneous state: ≤+10%
6) Frequency return time: ≤3s
7) Voltage deviation at stable state: ≤±1%
8) Voltage deviation at instantaneous state: ≤+20%
9) Voltage return time: ≤4s
10) Voltage modulation: ≤0.3%
Control system(Optional):
1) Automatic alarm system: acousto-optics test and alarm for start default,water over temperature, oil over temperature, over speed, oil over pressure and so on.
2) Operation display:
i) Unit voltage, tri-phase load current and frequency
ii) Water temperature, oil pressure
iii) Fuel level, fuel temperature
iv) Audible and visual alarm lamps and buzzers
Standard supply:
1) Diesel engine standard supply
2) Alternator
3) Steel mounting base
4) Flange connector
5) Ai/fuel/oil filter
6) On-board control panel
7) Shock absorber set
Optional Components:
Engine protection module,parallel equipment,common base oil tank,electric governor,automatic start,automatic transfer switch(ATS),remote- control equipment,sound-proof / weather-proof canopy,trailer type.
