Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set

Name: TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set
Brand: U-POWER
SKU: 124782953
Availability: InStock

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set thumbnail-1

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set thumbnail-2

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set thumbnail-3

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set photo-1

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set photo-2

TOP QUALITY !The Supply of 10-100KW Weifang Diesel Generator Set photo-3

US$ 2,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Shandong, China

Brand Name:

U-POWER

Model Number:

UP120GF

Contact Supplier Request Quote Chat Now

Weifang U-Power Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qindao China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shandong, China

Brand Name U-POWER

Model Number UP120GF

Output Type AC Three Phase

Speed 1500r/min

Frequency 50/60hz

Rated Power 120KVA

Rated Voltage 380

Rated Current 18-1440A

Specifications

1)70kva deutz powered
2)stable performance,energy saving 10%
3)deutz engine,Stamford generator
4)global warranty for1 year

Deutz powerd diesel generator for sale 20-120kw 50/60HZ made in weifang city

One Selected Program model of our portable diesel generator set

Model of Diesel Generator	UP50GF
Prime Output(KW/KVA)	40KW/50KVA
Max Output(KW/KVA)	44KW/55KVA

Model of Diesel Engine	TD226B-4D
Rated Output/Max output(KW)	45KW/49.5KW
Rated Speed (r/min)	1500rpm
Cylinders	4
Starting Method	Electrical
Governing Method	Mechanical/Electrical
Intake Method	Turbocharged
Fuel category	Diesel
Bore/Stroke	105/120mm
Cooling method	Water cooling
Fuel consumption(g/kW.h)	242.00

Model of Alternator	OEM Stamford Alternator
Rated Power(KW/KVA)	40KW/50KVA
Rated Frequency	50HZ
Rated Speed	1500rpm
Rated Voltage	400/230V
Power Factor(cos)	0.8(lag)
Excitation	Brushless
Connection	3phase-4wire
Insulation grade	H

Control System	display meters of oil pressure,rotation speed,water temperature,oil temperature,current,voltage,frequency.

Standard Equipments	Diesel engine: 1set
	Alternator:1set
	Common iron base:1set
	Display meters: 1set
	Shock absorber set
	Air filter:1set
	Fuel filter:1set
	Oil filter:1set
	Mechanic governor: 1set
	Technic file: 1set
	Standard spare parts:1set

Control system(Optional):

1) Automatic alarm system: acousto-optics test and alarm for start default,water over temperature, oil over temperature, over speed, oil over pressure and so on.

2) Operation display:
i) Unit voltage, tri-phase load current and frequency
ii) Water temperature, oil pressure
iii) Fuel level, fuel temperature

iv) Audible and visual alarm lamps and buzzers
Optional Components:

Engine protection module,parallel equipment,common base oil tank,electric governor,automatic start,automatic transfer switch(A

TS),remote- control equipment,sound-proof / weather-proof canopy,trailer type.

Warranty :1year or 1500hrs(the first reach is valid).

WHY CHOOSE US?

1)Ten years experience,make us more professional than other suppliers.

2)Quick delivery: 7-15 working days delivery time

3)Perfect after sale service: provide internatinal warranty service.

4)Pay attention to quality: 3 hours test before out factory

5) Environmental protection and energy saving : low noise, low emission,low fuel consumption.

6)Once establish business relationship in the long way, can share our VIP price.

Packing	plywood case
Packing
Unit Price	FOB QINGDAO,
Payment Terms	T/T30% deposit,after collection,arrange production.The 70% should be paid before the shipment.When got full payment,we release the full set of Original DOCS.
Delivery Time	10 working days after received 30%deposit
MOQ	1SET
Warranty	1year/1500hrs

Above table is just a reference of our product, in fact we can manufacture diffetent kinds of diesel generator with different power and performance, we are sincerely looking for partners to develop oversea market together, any questions free to let

us know,your kindly feedbacks and suggestion will be highly appreciated.
