Specifications
DEUTZdiesel water pump set1)Engine DEUTZ
2)Energy saving 10%
3)High quality,competive price
4)AMF optional
DEUTZ Diesel water pump set
Usage: Farm irrigation,fire fighting,industrial water supply system
Treated Water: Fresh water,River water
Outflow:30-2016m³/h
Head Lift:7-120m
Diesel engine parameters:
1)Model:D226B-3D
2)Rated output/Max output(KW):30/33KW
3)Rated speed(r/min):1500
4)Starting method: Electric motor 12V DC
5)Cooling method: Closed water cooling
6)Governing method: Mechanical/Electronic governing(Optional)
7)Intake method: Natural aspiration
8)Cylinders:3
9)Bore/Stroke:105/120mm
10)Type: in line,4 stroke, humid liner, direct injection
Water pump parameters:
1)Model:IS150-125-315
2)Type: Single grade, single suction,centrifugal
3)Outflow:240m3/h
4)Head:29m
5)Shaft power:23.7KW
6)Inlet diameter:150mm
7)Outlet diameter:125mm
8)Casing material: cast iron
9)Shaft material: cast iron
10)Impeller material:cast iron
11)Sealing method: Stuffing sealing/Mechanical sealing(Optional)
Control system(OPTIONAL):
1) ATS function
2)Warning of oil low pressure, slow speed, high water temperature, high oil temperature etc
3)Display functions with warning ,start and stop
Standard equipment:
1)Diesel engine: 1set
2)Water pump: 1set
3)Control panel: 1set
4)Flexible shaft joint: 1pc
5)Common base:1set
Fuel tank:optional
6)Accessory spare parts 1set
7)Technical file: 1set
8)With affiliated sensors and sensor wires
9)Inlet/outlet flange,bolt&screws,bottom valve and filters (OPTIONAL)
Quality Gurantee:1year/1500working hours(the first reach is valid )
