2 Inches, 3 Inches Agricultural Irrigation Diesel Water Pump With Price

FOB Price

US$ 2,000 - 3,000 / Set

1 Set(Min. Order)

Port Qingdao China
Payment TermsT/T Money Gram Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	U-power
Model Number	4B3.9-G1	Theory	Centrifugal Pump
Structure	Multistage Pump	Usage	Other, Water, irrigation diesel water pump
Power	Electric	Standard or Nonstandard	Standard
Fuel	Diesel	Pressure	Low Pressure
Application	Other, agricultural irrigation, Agricultural Drought floods

Product Description

Agricultural irrigation diesel water pump

Diesel Pump used agricultural irrigation diesel water pump specifications
agricultural irrigation diesel water pump
Water Pump Model	IS/SH/OS/WG/HW-S series water pump,etc
outflow(m3/h)	30-10000
head lift (m)	1000-7
suction lift height(m)	2-9
inlet diameter(mm)	50-800
outlet diameter(mm)	50-700
rated speed(r/min)	1450/1480
Diesel engine
Engine brand	Weifang Ricardo series,WEICAHI,Deutz,etc or as your require
Engine model	famous brand
rated power(KW)	10-1200
rated speed(r/min)	1500
cylinder number	2/4/6/8/12
starting method	electric
cooling method	water cooled
speed mode	mechanical(electric optional)
control panel	display: water&oil temperature,oil pressure,speed
Standard equipments
diesel engine: 1 set	common base:1 set
water pump: 1 set	shelf of storage battery
Optional equipments
Installation of electronic speed	Four electromagnets shutdown protection
Diesel Monitor	Control cabinet
common base with 8hrs fuel tank	Low Noise Speaker
weather-proof canopy	Trailer with fuel tanks, four battery holder, hand brake

Product Description

Pump:
1 Famous brand:Luyuan,NANFANG,etc
2.Housing, impeller made ??of high quality steel and other materials, coated with anti-rust paint quality, aesthetics, good corrosion resistance
3.Can be used for irrigation, drainage, fire protection, dredging, mining, construction, etc.

Diesel engine:
1.Selection Weichai, Deutz etc.Famous brands engine
2.Low fuel consumption, low emissions, low noise
3.Overseas 243 special service stations, providing high-quality, efficient service

Control system:
1.Automatic power shutdown, data measurement, alarm protection and 'three remote' feature
2.Large-screen liquid crystal (LCD) multi-language graphical display
3.Function can be realized by the governor pressure stabilization

Couplings:
1.High-strength elastic coupling, can deliver high torque
2.Damping, high damping performance, reduce the failure rate
3.Easy maintenance, long service life

Base:
1.Welding of high strength steel channel base
2.Low vibration at work, improve unit life
3.Coated with anti-rust paint quality, good corrosion resistance

Packaging & Shipping

Packging: plywood case or as per customers' requirements

Delivery time: 15-21 days(once the deposit is received)

Our Services

1) We are committed to provide personalized solutions of the diesel water pump for global clients.

2) Our products have a lifetime of archives, and a lifetime parts service is been provided by us.

3) The water pumps are powered by Ricardo,Weichai Deutz, Steyr diesdiesel engine, which have the global maintenance service.

4) There are so many authorized service stations where you can get maintenance serviceand spare

parts.

5) The warranty is 1500 running hours or 1 year (whichever comes first).

6) Quick production efficiency,transportation,after-sales service in place.
