90W High Pressure Sodium Lamp,Single Lens LED Street Lights

90W High Pressure Sodium Lamp,Single Lens LED Street Lights thumbnail-1
90W High Pressure Sodium Lamp,Single Lens LED Street Lights photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
CREE, CREE LED
Input Voltage(V):
100-277 VAC
Lamp Power(W):
90
Contact Supplier Request Quote Chat Now
Shenzhen Spark Optoelectronics S&T Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source CREE, CREE LED
Input Voltage(V) 100-277 VAC
Lamp Power(W) 90
Lamp Luminous Flux(lm) 8550
Lamp Luminous Efficiency(lm/w) 95
Working Lifetime(Hour) 50000
Certification CE, CQC, FCC, PSE, UL, VDE
Place of Origin Guangdong, China
Brand Name spark
Model Number SPL-C90

Spark is proud of its High Power Street Illumination Series. High Power Street Illumination is a new serie of energy saving products that utilize high power LEDs as effective lighting source to traditional illumination, such as LPS, HPS, or MH street lights. LED Street Illumination provides a multitude of advantages over conventional incandescent light: LED Street Illumination is environmentally friendly, energy efficient, and cost-effective. This smart, "greener" option for outdoor lighting has emerged on the green scene due to the recent technological advancements of LED Street Illumination.


Whether you’re looking for best lights or lamps for use, you’ll find the LED Street Illumination solution for your needs at our company-Spark. Our LED light selection includes LED bulb, LED Street Illumination, LED tunnel light, LED tube and more. Choosing LED Street Illumination from “Spark” today, enjoying green future!





  • Die casting aluminum alloy housing, electrostatic spraying treatment, coating withstand high temperature, acid & alkali resistance and anti-aging

  • Arc-shaped heat sink, self-cleaning ability improved by residue including dust easily carry away with rainfall

  • Installation angle adjustable, horizontal and vertical installation available

  • Independent optical system for each LED, light transmittance over 93%, high lamp luminous efficacy





Main Technology Index:



Model No. SPL-C90
Replacement 150W High Pressure Sodium Lamp
LED Light Source CREE LED
LED Quantity 60 pcs
LED Working Current 400 mA
Lamp Rated Total Power 90W
Power Efficiency > 90%
LED Luminous Efficiency 100-122lm/w
Lamp Rated Total Luminous Flux 8550lm
Lamp Rated Luminous Efficiency 95lm/w
lllumination and Effective Area Effective Area
Height 6M 24X6M/50 lux
Height 8M 34X8M/28 lux
Height 10M 40X10M/18 lux
Height 12M 50X12M/12 lux
Color Rendering Index Ra>70
Color Temperature Cool white: 5000-5700K
  Pure white: 4000-4500K
  Warm white: 3000-3500K
Beam Angle Horizontal Axis:60°
  Vertical Axis:130°
Light Distribution Curve Asymmetric (Bat Wing) / Rectangular Beam
Input Voltage AC 100-277V
Frequency Range 47-63Hz
Power Factor(PF) ≥ 0.95
Total Harmonic Distortion < 15%
Storage Temperature -40°C--+80°C
Working Environment -40°C--+50°C; 10%-95%RH
Junction Temperature 60°C±10%(ta=25°C)
Light Body and Lampshade Material Aluminum Alloy
Working Lifetime > 50,000hrs
IP Rating IP66
Net Weight 12.8kg
Gross Weight 14.9kg
Product Dimension (mm) 865(L)×335(W)×109(H)mm
Package Size (mm) 937(L)×396(W)×170(H)mm
