35W Mini LED Street Light

35W Mini LED Street Light thumbnail-1
35W Mini LED Street Light photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Lamp Power(W):
35
Lamp Luminous Efficiency(lm/w):
75
Working Lifetime(Hour):
50000
Contact Supplier Request Quote Chat Now
Shenzhen Spark Optoelectronics S&T Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Lamp Power(W) 35
Lamp Luminous Efficiency(lm/w) 75
Working Lifetime(Hour) 50000
Certification CE, CQC, FCC, PSE, UL, VDE
Place of Origin Guangdong, China
Brand Name SPARK
Model Number SPL-M30

30W Mini LED street lighting

SPARK Mini LED Street lighting adopts a new independent intellectual property right of the intelligent driver. Leaded by a central control system, LED Street lights can control the lamp brightness from 0-100% and feedback the working situation of each lamp to the central control system by remote control, and this kind of function can highly improve the management efficiency of road lighting administrative authority. At the same time, it is also more benefit for EMC energy investment companies to control the electricity charge and cost. And SPARK Mini LED Street lighting is the best city lighting energy-saving solution for EMC to recoup the investment rapidly and effectively.



Whether you're looking for best lights or lamps for use, you'll find the Mini LED Street lighting for your needs at our company-Spark. Our LED light selection includes LED bulb, LED Street light, LED tunnel light, LED tube and more. Choose Mini LED Street lights from "Spark" today, then enjoy and experience the future of light!



Characteristics of Mini LED Street lighting:



1. More than 70% energy saving

2. 4x6 LED display module design, easy for maintenance

3. Original American CREE LED or Philips Lumileds LED used

4. Universal input voltage: 85-300v AC

5. Second time energy saving by light control and time-phase power control

6. High quality power supply, reliable and stable, automatically reduce current against high working temperature

7. Unique optical design, rectangular beam, suitable for roadway illumination



Please NOW feel free to contact us for customized Mini LED Street lighting Project.



35W Mini LED street light



Main Technology Index of Mini LED Street lighting:

Model No.Mini LED Street lighting SPL-M30
Replacement75-100W High Pressure Sodium Lamp
LED Light Source30 × 1W CREE LED/LUMILEDS Rebel LED
LED Luminous Efficiency107-122 lm/w
Lamp Total Power36W
Power Efficiency> 85%
Lamp Total Luminous Flux> 2,500lm
Lamp Luminous Efficiency> 75lm/w
Average lllumination and Effective Area4M Height13m×5m ≥32LUX
6M Height20m×8m ≥18LUX
8M Height26m×10m ≥12LUX
Color Rendering Index(CRI)Ra>75
Color Temperature(CCT)Cool white: 5000-6500K
Pure white: 4000-5000K
Warm white: 2700-3500K
Beam AngleHorizontal Axis:120°
Vertical Axis:60°
Light Distribution Curve(Beam Pattern)Asymmetric (Bat Wing) / Rectangular Beam
Input Voltage85-300V AC ; 12V DC/ 24V DC
Frequency Range50-60Hz
Power Factor(PF)> 0.98
Total Harmonic Distortion(THD)< 20%
Storage Temperature-40°C--+80°C
Working Environment-40°C--+50°C; 10%-95%RH
Junction Temperature(Tj)60°C±10%(ta=25°C)
Light Body and Lampshade MaterialAluminum Alloy and PC
Working Lifetime> 50,000hrs
IP RatingIP66
Net Weight6.5kg
Gross Weight7.5kg
Product Size (mm)646×242×87
Package Size(mm)700(L)×300(W)×250(H) (1PC)
