Spark High Power LED Tunnel Light 120W

Spark High Power LED Tunnel Light 120W thumbnail-1
Spark High Power LED Tunnel Light 120W photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
CREE/Lumileds
Input Voltage(V):
100-277VAC
Lamp Power(W):
120
Contact Supplier Request Quote Chat Now
Shenzhen Spark Optoelectronics S&T Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source CREE/Lumileds
Input Voltage(V) 100-277VAC
Lamp Power(W) 120
Lamp Luminous Flux(lm) 9600
Lamp Luminous Efficiency(lm/w) 80
Working Temperature(℃) -40, 80
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP65
Certification CE, CQC, FCC, PSE, UL, VDE
Place of Origin Guangdong, China
Brand Name Spark LED Tunnel Light
Model Number SPT-D120

Spark High Power LED Tunnel Light 120W

Spark High Power LED Tunnel Light 120W

Product Description:




1. Die casting aluminum alloy lamp housing with excellent heat dissipation; clear parts are high strength toughened glass; with a good performance of dust resistance, water resistance, and shock resistance.

2. Unique optical design & rectangular beam; every single LED matched with a reflection cup, which will properly control the light distribution, and ensure illumination and uniformity of light, meanwhile, eliminate LED glare.

3. Lamp and power driver are independently assembled with high overall reliability and convenient for maintenance.



Main Technology Index:


Model No.                                                       SPT-D120
LED Light Source CREE/Lumileds
LED Quantity 48 x 1 PCS LED
LED Luminous Efficiency 217 lm/700mA Cool white
Lamp Rated Total Power 120W ± 10%
Lamp Rated Luminous Efficiency      80 lm/w
LED Driver Current 700mA
Lamp Rated Total Luminous Flux      9,600 lm ± 10%
Average lllumination and Effective Area 3M Height 6m×7m ≥488LUX
4M Height 8m×9.5m ≥275LUX
5M Height 10m×12m ≥176LUX
6M Height 12m×14m ≥122LUX
Color Rendering Index(CRI) Ra>70
Power Efficiency 90%
Color Temperature(Color Temperture) Cool white: 5000-6300K
Pure white: 3700-5000K
Warm white: 2700-3300K
Beam Angle

100°X90°
Input Voltage 100-277VAC
Frequency Range 47-63Hz
Power Factor(PF) ≥ 0.95
Total Harmonic Distortion(THD) < 15%
Storage Temperature -40°C--+80°C
Working Temperature -40°C--+50°C ; 10%-90%RH
Junction Temperature(Tj) 85°C± 10%(Ta+25°C)
Light Body Material Aluminum Alloy
Working Lifetime > 50,000hrs
IP Rating IP65
Net Weight 8.4kg
Product Dimension(mm) 406(L) x 295(W) x 213(H) (mm)
Package Size(mm) 476(L) x 365(W) x 231(H) (1 PC)
