Home > Lights & Lighting > LED Outdoor Lighting > LED Tunnel Light > Spark NEW High Luminous Efficiency LED Tunnel Light 90W
Spark NEW High Luminous Efficiency LED Tunnel Light 90W
Negotiable
MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
CREE/Lumileds
Input Voltage(V):
100-277VAC
Lamp Power(W):
90
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Spark High Luminous LED Tunnel Light CE CQCNegotiableMOQ: 2 Pieces -
Spark New Release LED Tunnel Light, Modular Design, Hollow StyleNegotiableMOQ: 1 Piece
-
Spark 100W High Power LED Tunnel Lights With LEDNegotiableMOQ: 2 Pieces
-
200W High Power LED Tunnel LightNegotiableMOQ: 2 Pieces
-
Spark 150W CE&ROHS Approved LED Tunnel LightNegotiableMOQ: 2 Pieces
LED Light Source
CREE/Lumileds
Input Voltage(V)
100-277VAC
Lamp Power(W)
90
Lamp Luminous Flux(lm)
7200
Lamp Luminous Efficiency(lm/w)
80
Working Temperature(℃)
-40, 80
Working Lifetime(Hour)
50000
Lamp Body Material
Aluminum Alloy
IP Rating
IP65
Certification
CE, CQC, FCC, PSE, UL, VDE
Place of Origin
Guangdong, China
Brand Name
Spark LED Tunnel Light
Model Number
SPT-D90
Spark NEW High Luminous Efficiency LED Tunnel Light 90W
Product Description:
1. Die casting aluminum alloy lamp housing with excellent heat dissipation; clear parts are high strength toughened glass; with a good performance of dust resistance, water resistance, and shock resistance.
2. Unique optical design & rectangular beam; every single LED matched with a reflection cup, which will properly control the light distribution, and ensure illumination and uniformity of light, meanwhile, eliminate LED glare.
3. Lamp and power driver are independently assembled with high overall reliability and convenient for maintenance.
Main Technology Index:
| Model No. | SPT-D90 | |
| LED Light Source | CREE/Lumileds | |
| LED Quantity | 36 x 1 PCS LED | |
| LED Luminous Efficiency | 217 lm/700mA Cool white | |
| Lamp Rated Total Power | 90W ± 10% | |
| Lamp Rated Luminous Efficiency | 95 lm/w | |
| LED Driver Current | 700mA | |
| Lamp Rated Total Luminous Flux | 7,200 lm ± 10% | |
| Average lllumination and Effective Area | 3M Height | 6m×7m ≥388LUX |
| 4M Height | 8m×9.5m ≥218LUX | |
| 5M Height | 10m×12m ≥140LUX | |
| 6M Height | 12m×14m ≥97LUX | |
| Color Rendering Index(CRI) | Ra>70 | |
| Power Efficiency | 90% | |
| Color Temperature(Color Temperture) | Cool white: 5000-5700K Pure white: 4000-4500K Warm white: 3000-3500K |
|
| Beam Angle | 100°X90° |
|
| Input Voltage | 100-277VAC | |
| Frequency Range | 47-63Hz | |
| Power Factor(PF) | ≥ 0.95 | |
| Total Harmonic Distortion(THD) | < 15% | |
| Storage Temperature | -40°C--+80°C | |
| Working Temperature | -40°C--+50°C ; 10%-90%RH | |
| Junction Temperature(Tj) | 85°C± 10%(Ta+25°C) | |
| Light Body Material | Aluminum Alloy | |
| Working Lifetime | > 50,000hrs | |
| IP Rating | IP65 | |
| Product Dimension(mm) | 323(L) x 295(W) x 213(H) (mm) | |
| Package Size(mm) | 393(L) x 365(W) x 231(H) (1 PC) | |
