Specifications
1.low consumption.high output.2.Copetitive price.
3.Warranty one year.
wood plastic board production line
wpc/pvc celuka/skinned foam board machine
l it adopts Celuka foaming technology. Compared with PVC free foaming board, plastic celuka foam board not only has much more smooth surface, but also the hardness is better. In addition, mechnics performance of Celuka foam board is better than that of free foaming board, PVC Celuka foam board extrusion line is composed of conical twin-screw extruder, die, vacuum calibration unit, haul-off unit and so on. Our company can provide the formula and all the processing techniques. The machine has the features of high output, stable extrusion, high foaming, smooth and wearable surface. By equipping with the printing machine, laminating machine or hot stamping machine, this machine can produce different kinds of artificial wood products, so that this machine has a very wide application range.
plastic machine
The machine Type
1. SHRL-Z500/1000A High-speed Heat/Cooling mixing machine SRL-Z500/1000A 1 set
2. ZJF500 Automatic feed loader ZJF500 1 set
3. SJSZ80/156 Extrude SJSZ80/156 1 set
4. Mould 1 set
5. Calibration platform 1 set
6. Bracket 1 set
7. Haul off machine 1 set
8. Through cutter 1 set
9. Cross cutter 1 set
10. Stacker 1 set
11. Crusher 1 set
Eletrical Part
1. Main motor frequency controller: ABB
2. Temperature controller: OMRON or RKC
3. AC controller: Schneider or simens
4. Thermal overload relay: Schneider
Thickness (mm) | 1mm to 30mm |
Width (mm) | 1220,1560 |
Length (mm) | 2440,3050 |
Standard Color | White |
Density (g/cm3) | 0.45 – 0.8 |
Pulling strength(MPa) | 12-20 |
Bending strength(MPa) | 12-18 |
Elastic modulus in bending (MPa) | 800-900 |
Impact strength (KJ/m2) | 8-15 |
Breaking elongation (%) | 15-20 |
Vicat softening point | 73-76°C |
Shore hardness | 45-50 |
Water absorbing capacity (%) | ≥1.5 |
Flame retardancy | The self-extinguishing time away from the flame is less than 5 seconds |
Specification:
Model | Extruder | Width | Thickness | Capacity |
S1220 | SJSZ80/156 | 1220mm | <30mm | 350KG |
S1830 | SJSZ92/188 | 1830mm | <30mm |
