Specifications
PET bottle recycling production line1.Capacity:300-2000kg/hr
2.Crusher's power:55kw
3.low noise
4.easy operation
PET bottle recycling production line
PET bottle recycling production line also is called PET bottle crushing, washing machine. It has considered the usage condition of our domestic market and has combined the advance technology of international recycling machines, it is special designed for
recycling of different kinds of PET bottles. The production procedures are as follows: selection, label removal, crushing, heating stirring,friction washing and two poaching washing. After these washing procedures, the washed PET flakes can meet the requirement of next application.
The recycled product is widely used in chemical fiber spinning, granulation, injection and etc fields. This machine has the features of high automation, clean washing , high productivity .
Feature
1.high output
2.high efficiency
3.stable work operation performance
4.reasonable price and de sign
The machine charts
NO | ITEM | DESCRIPTION | SELECTIVITY |
1 | Prewasher | Remove the solid impurity which are water insoluble, such as hand stone, sand, etc. It can also wash bottles' surface. | Optional |
2 | Bale Breaker | It is used in large capacity recycling line, and bottles are compressed in bale. | Optional |
3 | Belt Conveyer | Including the metal detector. | Necessary |
4 | Label Remover | Label removing efficiency, more than 98% | Optional |
5 | Manual Select Platform | Made according to workers' height, supply a suitable plate for selecting the left labels or some other impurity. | Optional |
6 | Belt Conveyer | Conveying the bottles into crusher. | Necessary |
7 | Crusher | With water, the materials of the blade adopt SKD-II or 9CrSi. It has a function of prewashing too. | Necessary |
8 | Screw Feeder | Conveying the flakes into friction washer. | Optional |
9 | Friction Washer | Scrubbing material in high-speed with water. | Optional |
10 | SCrew Floating Washer | Remove few remand paper, sand, label from material based on different density. | Optional |
11 | Screw Feeder | Conveying the flakes into hot washer. | Necessary |
12 | Hot Washer | High temperature stirring washing with caustic soda. Water can be heated by steam or electric. | Necessary |
13 | Screw Feeder | Same as Item 8. | Necessary |
14 | Friction Washer | Same as Item 9. | Necessary |
15 | Screw Floating Washer | Same as Item 10. | Necessary |
16 | Dewatering Machine | High speed centrifuge drying. | Necessary |
17 | Drying System | Electric heating wind drying. | Necessary |
18 | Label Wind Separator | The last left impurity will be separated from flakes by the blower fan. | Optional |
19 | Silo | Store the final material. | Necessary |
20 | Electrical Control Panel | Adopts Siemens and DELIXI as main component. | Necessary |
If you customer have interest in the washing line ,please let me know your finnal flakes size and capacity requirements ,that will make me offer more exact and reason price and save your valuable time.
