PVC Double Pipe Making Line
1. Brife introduction of PVC Double Pipe Making Line :
The production line is developed for high output of twin-pipe extrusion. The main machine is SJSZ51/105 or SJSZ65/132 conical double-screw extruder, is equipped with double-tube single-control stainless steel spraying shaper to form a production line. It avoids a waste condition when one tube is adjusted and the other one is affected. The auto single-control double drawing machine and cutting are combined with the front shaping technology to make operation more flexible. Let you enjoy economic benefit which is brought about by separately control double-tube extruding. The diameter of the extruded pipe is from Φ20-Φ63(mm). It can fully use the extruding capacity of the extruder.
2. Main technical datas of PVC Double Pipe Making Line :
Pipe range |
16-40mm |
16-63mm |
Extruder |
SJZ51/105 |
SJZ65/132 |
Extruder power |
18.5kw |
37kw |
Extrusion capacity |
120kg/h |
250kg/h |
Max. Production speed |
2 x 8m/min |
2 x 10m/min |
3. System configuration of PVC Double Pipe Making Line :
Item |
Machine |
Quantity |
1 |
Spring loader |
1 set |
2 |
Conical Twin-Screw Extruder |
1 set |
3 |
Double-extrusion die and head, as required wal thickness |
complete set |
4 |
Double Vacuum Calibration tank |
1 set |
5 |
Printer wheel typ |
2 sets |
6 |
Double Hauling & Cutting Machine Combination |
1 set |
7 |
Double Pipe stacker |
1 set |
Plastic Extruder
Vacuum Tank
Double Haul-off machine
Factory Picture
