Zhangjiagang Friend Machinery Co., Ltd. is a professional company specializing in the design and manufacture of plastic machines, such as single screw extruders, conical twin screw extruders, PVC, PE, PP and PP-R pipe extruders, PVC and PE profile extruders, PVC and PE recycling machines, crushing, washing and pelleting machines, conveying and mixing machines for all kinds of plastics and other kinds of auxiliary equipment in the field.
Our company is well known both at home and abroad for high quality products and complete service systems. Our products sell well all over the world.
If you are interested in any of our products, please feel free to contact us for more information.
PVC Hot-Cutting Granulating Line]
Process flow:
Raw material+ additive → Mixing → Conveying feeding → Force feeding → Conical twin screw extruder → Blowing hot-cutting mould → Cyclone separator → Vibrating screener → Blowing system → Storage hopper → Finished product packing
This production line produces pellets by hot cutting, mainly PVC pellets. It is featured as advanced equipment, precise pelletizing and high producing capacity.
Feature:
1. Conical double-screw extruder, very suitable to process PVC powder with high capacity
2. Pelletizing style: Hot-cutting on mould face, even cutting ensures good shape.
3. Auxiliary machine: Pellets cooling & classifying
| Extruder type | SJSZ51/132 | SJSZ55/110 | SJSZ65/132 | SJSZ80/156 | SJSZ92/188 |
| Motor power | 18.5kw | 30kw | 37kw | 55kw | 110kw |
| Capacity | 120kg/h | 200kg/h | 250kg/h | 350kg/h | 800kg/h |
