Place of Origin Germany
Brand Name J. v. G. Thoma
Type Other
Quality assurance is an absolute imperative in the PV manufacturing. The solar specialist J.v.G. Thoma, based in Bavaria, is about to present on the dot at the industrial trade fair PV-SEC its new flasher model: the worldwide first LED based inspection device in the market. Its advantage? With it the test results will be more accurate than with conventional devices.

Freystadt/Oberpfalz - The better one beats the good one: that is the philosophy of Diplom-Ingenieur Hans Thoma, General Manager of J.v.G. Thoma GmbH. That is why the company also continued to work on the development of its existing high-performance flasher, despite good performance. And now it focuses on the strong points of LEDs.

With the new flasher each module is put to the acid test not just once, but five times in one go. From this an average is derived which in turn will en Quality assurance is an absolute imperative in the PV manufacturing. The solar specialist J.v.G. Thoma, based in Bavaria, is about to present on the dot at the industrial trade fair PV-SEC its new flasher model: the worldwide first LED based inspection device in the market. Its advantage? With it the test results will be more accurate than with conventional devices.

Freystadt/Oberpfalz - The better one beats the good one: that is the philosophy of Diplom-Ingenieur Hans Thoma, General Manager of J.v.G. Thoma GmbH. That is why the company also continued to work on the development of its existing high-performance flasher, despite good performance. And now it focuses on the strong points of LEDs.

With the new flasher each module is put to the acid test not just once, but five times in one go. From this an average is derived which in turn will ensure that the results are more accurate. And that means, later for the dimensioning all wiring connections can be done much more precisely.

Faster than lightning: from zero to five in 0.1 seconds

Price: up to 49.200 Euro

The amazing thing about the LED variant is that it requires less time to determine these five readings than a common flasher for only one reading. There is an obvious reason behind this: the LED light burns continuously, whereas a conventional flasher takes nearly 20 seconds until the condenser is recharged for the next "flash light".

A series-ready achievement

When the n
Product Description



Capacity: > 30 MWp
Wafers/h: 1000
Uptime: 85 %
Yield: 96 %
Efficiency: 18.5 %
Working time: 24 h / 360 days

Actual available

2 furnace (Centrotherm with full automation) for doping
1 PECVD system fully automated
1 Printing line with centrotherm and ASYS (Ekra) printer
Wetchemical  batch machines for saw removal and texturing (Mono/Multi)
Celltester & Sorter
Offline measurement equipment
Spare parts
Capacity: > 30 MWp
Wafers/h: 1000
Uptime: 85 %
Yield: 96 %
Efficiency: 18.5 %
Working time: 24 h / 360 days

Actual available

2 furnace (Centrotherm with full automation) for doping
1 PECVD system fully automated
1 Printing line with centrotherm and ASYS (Ekra) printer
Wetchemical  batch machines for saw removal and texturing (Mono/Multi)
Celltester & Sorter
Offline measurement equipment
Spare part Stringer GT 2 BB

Price: 39.000 EUR

When you need more information, please contact us. s
J.v.G. vertical Glas Washer

Price:  39.000 €
J.v.G. led cell tester - 30 x 30 cells

J.v.G. Offgrid solution - a maximum output of 400 to 2.000 W

Simply "plug & play"

The "JvG Of­f­grid So­lu­tion-Box" is con­nected quickly and eas­ily:


Sim­ply con­nect the box el­e­ments with the cable, flip the switch and the light turns on! All four vari­ants offer - de­pend­ing on the En­ergy-Box fea­tures - a max­i­mum out­put of 400 to 2.000 W. With the "So­lu­tion-Box" type I, for ex­am­ple, a row with up to three in­stalled mod­ules and up to eight bat­ter­ies is pos­si­ble, type IV of­fers the pos­si­bil­ity of up to 4 rows with 3 mod­ules each and up to six­teen bat­ter­ies gen­er­at­ing and stor­ing solar elec­tric­ity. The lat­ter type with the high­est out­put of 2.000 W can even power a wash­ing ma­chine.


Proven and tested photovoltaic technology

Of course, an im­por­tant part of the "JvG Of­f­grid So­lu­tion-Box" are the em­ployed mod­ules that con­vert sun­light
into elec­tric­ity. In our case, these mod­ules are poly­crys­talline JvG OF­F­GRID mod­ules. Up to nine of these mod­ules can be con­nected to the "JvG Of­f­grid So­lu­tion-Box".

Highly capable and compliant – "TEC-approved – JvG SOLAR-developed"

The main ac­tors of the "JvG Of­f­grid So­lu­tion-Box" are the JvG OF­F­GRID mod­ules. This is why they were also tested for re­li­a­bil­ity and per­for­mance in ex­em­plary ex­treme sit­u­a­tions by the TEC In­sti­tute for Tech­ni­cal In­no­va­tion, head­quar­tered in Bavaria, Wal­daschaff. These tests are per­formed under re­al­is­tic con­di­tions for longer pe­ri­ods of at least six months to one year. Whether ex­posed to heat and cold or de­struc­tive en­v­i­ron- men­tal in­flu­ences such as an am­mo­nia at­mos­phere – the JvG OF­F­GRID mod­ules passed all re­silience tests with fly­ing colours. TEC work to op­ti­mise prod­ucts and pro­vide qual­ity as­sur­ance, among oth­ers on be­half of the J.v.G. Thoma GmbH, one of the lead­ing sup­pli­ers of state-of-the-art solar tech­nol­ogy in Ger­many and Eu­rope.

The perfect photovoltaic solution for your own energy production!


From light bulbs to stereo systems - complete systems tailored to meet individual power requirements

What to do if there is no power sup­ply con­nec­tion? Quite sim­ple - the so­lu­tion is to gen­er­ate and store it your­self and use it when needed. Whether you need power for light­ing, a tele­vi­sion, fan, re­frig­er­a­tor or wash­ing ma­chine, with the dif­fer­ent „JvG Of­f­grid So­lu­tion-Box“ („en­ergy keep it sim­ple & safe“) mod­els, this won‘t be a prob­lem!

As the name al­ready im­plies, the en­ergy box con­sists of three com­po­nents: PV mod­ules that gen­er­ate elec­tric­ity using the sun, in­vert­ers that con­vert this elec­tric­ity to al­ter­nat­ing cur­rent and bat­ter­ies that store the gen­er­ated elec­tric­ity - safe and sim­ple.

Ideal for places with­out a pub­lic grid where one is in­evitably de­pen­dent on self-suf­fi­ciency and self­gen­er­a­tion.
SOLAR MOD­ULES JvG Of­f­grid So­lu­tion-Box guar­an­tees this self­suf­fi­ciency!

All com­po­nents are as­sem­bled into a com­plete user-friendly sys­tem. Type 1 (di­rect cur­rent) of­fers the out­put re­quired, for ex­am­ple, for 12 V en­ergy-sav­ing lamps and other 12 V de­vices. With types 2 to 4 (al­ter­nat­ing cur­rent), the us­able out­put amounts to a max­i­mum of 2.000 W. This makes it pos­si­ble to op­er­ate 230 V elec­tri­cal de­vices like a nor­mal power socket!

With one dif­fer­ence, how­ever:

This elec­tric­ity is def­i­nitely green be­cause of its en­vi­ron­men­tally friendly gen­er­a­tion!

Load 12V DC/230V AC

- 12V-Load maxi 100 W / 250W / 500 W /  750 W / 1000 W / 2000 W, for example for small fans
- USB and / or 230-connection (without earthing contact)
- 230-Load (without protective contact) max. 100 W for e.g. 230 V lamps, small fans, battery chargers, laptop etc.
- e.g. can charge up to a max. of 10 mobile phones simultaneously

Additional Information

- Max. 100 W for 5 V DC (via USB adapter) or 12 V DC or 230 V AC
- Strap for carrying box, on-off switch for battery protection
- Lead dry-cell battery, maintenance-free (10 Ah, 12 V DC)
- When operating 100 W consumer max. 0.5 hours

NOTE: Operating hours depends on the different load, solar irradiance and the battery.



When you need more information, please contact us via contact form:

http://www.jvg-thoma.de/en/offgrid-system/
