Very well to use slag stopping plug delivery device
- 120 Set / Sets per Month
- SHANGHAI/DALIAN
- T/T L/C D/P D/A Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Double Platform Stainless Steel Kitchen Equipment Polishing Machine
- Photovoltaic solar panels recycling plant
- Solar panel recycling machine with high efficiency
- Micro wire mesh weaving machine from LANYING wire mesh weaving machine
- LANYING woven wire mesh machines - stainless steel wire mesh weaving machines
Product Details
Place of Origin: | Anhui, China | Brand Name: | YunTian | Model Number: | YTD-2 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Very well to use slag stopping plug delivery device
The slag stopping delivery device is a special device used for optimizing the production of basic oxygen furnace steelmaking. It improves the quality of the steel by reducing the slag mixed into the ladle and reducing the loss of ferroalloy.
When the converter releases the molten steel, the device puts a slag-stopping plug into the tap hole to prevent the liquid slag mix into the ladle.
After the device completes the whole process, there is a significant reduction of slag mixed in the ladle, and by reducing the alloy consumption, steelmaking process along with economicaladvantage is highly improved.
Technical Specifications Table
Features | Items | Parameter | Value | |
Platform Dimensions | Dimensions | Width | 1400 mm | |
Length | ~2150 mm | |||
Moving speed | 0~30m/min. | |||
Location Accuracy | ±10mm | |||
Forward Engine | Voltage | AC 380V | ||
frequency | 50Hz | |||
power | 1.5 Kw | |||
Track
| Track type | 24 kg/m | ||
Center distance | 1200mm±0.5mm | |||
Rotating Platform | Rotation Angle | -2°~+92° | ||
Rotation Speed | 0.5-1r/min | |||
Cantilever Rod | Diameter of Plug Rod | 14-16 mm | ||
Tilting Angle | Up ~ 5° Down 18° max | |||
Cooling Type | Compressed air | |||
Tap Hole Calibration | Angle Range | ±2° | ||
Horizontal Calibration Range | ±250mm | |||
Centering Speed | 2mm/sec. | |||
Centering Engine | Voltage | AC 380 V | ||
Frequency | 50 Hz | |||
Power | 0.37 KW | |||
Hydraulic Port | Pressure | 16 MPa | ||
Flow | 16l/min | |||
Oil Pump Engine | Voltage | AC 380 V | ||
Frequency | 50 Hz | |||
Power | 2.2 Kw | |||
Hydraulic Solenoid Valve | Voltage | DC 24V | ||
Compressed Air | Pressure | 0.4 ~0.6 Mpa | ||
Consumption | 900 l/min |
According to the customer’s need
Advantages
ü REDUCED slag carryover
ü CUSTOM BUILT insertion machine
ü ADVANCED refractory components
ü COMPATIBLE with an Infra-Red Camera System for slag detection
ü COMPETIVE price and quality
Why choose us?
1.Our company has a sound service system,and good follow-up by professional person at each step like technical guidance and maintenance in each of the areas , so customers will not have worries .
2.As a national high-tech enterprise,we have more than 15 years experience in slag-stopping industry, we obtained the patent of slag dart in 2009.
3.To ensure the product quality and consistency,we have obtained the ISO 9001 quality system certificate
Anhui Yuntian Metallurgy Technology Co.,Ltd specialized in the research and engineering of slag control system including refractory darts and machines for BOF,and is a leading supplier for the development,production and sales. We have our own material & technology research center, With specialized production craft technology,complete quality system.YUNTIAN® is the first company of its same trade that has passed the ISO9001 International Quality Management System Certification.
With stable quality management system, hard-working staff, process optimization, integrity and high level development capability, our products has been saled to all over the world and satisfied customer requirements on quality, delivery, service, prices, rules and regulations.
All employees in YUNTIAN understand and implement quality guidelines. Quality assurance and improvement enjoy privileges. The company continuously optimizes its products and service. We devote ourselves to customer satisfaction.YUNTIAN®, sticking to the principle of Sincerity First, Quality Guaranteed, Price Concession, and Timely Service, is willing to cooperate with both new and old customers to create a better future for all.
1.Q:Does your company offer free sample?
A: Yes, we can offer free sample ,we will not pay for the shipping cost
2.Q:Does your company accept any factory inspection?
A: Yes,we accept customer inspection and third party inspection
3.Q:Does your company have any overseas technical guide or training for ?
A: Yes,we will send professional person to your company to train your workers if need. This is only apply to slag control equipment.
4.Q:Can your slag dart be used if we have other company’s dart application machine like “Monocon” ?
A: Yes, you just need to tell us the specification of the darts,we can design&produce the right dart.
5.Q: Can i be a distributor of YUNTIAN?
A: Of course you can.
6.Q:What are the benefits of being a YUNTIAN distributor?
A:-Special discount
-Marketing protection.
-Point to point technical supports and after sales services.
7.Q:How can i become a distrubutor of YUNTIAN?
A:Contact us immediately for futher details by sending us an inquiry.
