Carbon Steel Welding Road E6013 Introduction
1. Model No.: Welding Rod AWS E6013(J421, J38.12)
2. Available size: 2.5x300mm, 2.5x350mm, 3.2x350mm, 4.0x400mm, 5.0x400mm
3. Packing: 5kgs/box, 20kgs/carton, 1000kgs/pallet, we could do according to the customers ‘request.
4. Delivery time: Within 20 days after confirmation
5. Application: The E6013 welding rods are widely used on both AC and DC in all position and suitable for welding sheet metal structure made of low-carbon steel, such as ships, vehicles, building, and general machinery.
Detaild Specification for Carbon Steel Welding Rod E6013 (J421, J38.12)
Chemical Compossition of Deposited Metal (%)
|
C |
Mn |
Si |
S |
P |
Guaranteed value |
≤0.12 |
0.3~0.6 |
≤0.35 |
≤0.035 |
≤0.040 |
Typical value |
0.07 |
0.4 |
0.25 |
0.019 |
0.025 |
Sizes, Length & Recommended Current (AC/DC)
Diameter (mm) |
φ2.0 |
φ2.5 |
φ3.2 |
φ4.0 |
φ5.0 |
Length (mm) |
300 |
300 |
350 |
400 |
400 |
Current (A) |
40~70 |
50~90 |
90~130 |
130~210 |
170~230 |
Mechanical Properties of Deposited Metal
|
Rm (Mpa) |
ReL(Mpa) |
A(%) |
KV2(J) |
KV2(J) |
Guaranteed value |
σb≥420 |
σs ≥ 330 |
δ5 ≥ 17 |
(normal temperature) |
-(0°C) |
Typical value |
460~540 |
≥ 340 |
18~26 |
50-80 |
≥ 47 |
Shandong Huaxiang Import and Export Co., Ltd
It is an enterprise which specialized in stainless steel ,carbon stel and copper products.honest and trustworthiness ,super quality and competitive price are the objective of our business.we have high-speed service ,good communication and interpersonal skills.and formed a complete set of system for export.we have customers all over the world, like Russian ,Singapore, Canada, Australia.
skype:xjwy-helen qq:346087522
whatsapp:86-13863580997
tel:86-0635-2929880 fax:86-0635-2929881
we are warmly welcome you to contact us!
