Obm-6802 Cheap Barcode Scanner 2d Barcode Scanner Module 2d Barcode Reader Price
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Type:
Barcode Scanner
Scan Element Type:
Other, Laser
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Saints-M3B Mini Bluetooth Barcode Scanner / Portable Barcode Scanner / Laser Speed GunsNegotiableMOQ: 10 Pieces -
Saints-380 Wireless Supermarket Oem Laser Barcode Reader/scanner 1d With Usb/rs232/ps2US$ 48 - 53MOQ: 10 Pieces
-
Saints-9800 Wireless Bar Code Reader, Portable Laser Barcode Scanner Handheld Data Transfer Collection DevicesNegotiableMOQ: 1 Piece
-
Wireless Laser Portable Barcode Data Collector Handheld Inventory Barcode ScannerNegotiableMOQ: 1 Piece
-
Saints-767 Wireless Laser Handheld Pda Data Collection Device,usb Wireless Barcode ScannerNegotiableMOQ: 10 Pieces
Products Status
Stock
Type
Barcode Scanner
Scan Element Type
Other, Laser
Colour Depth
32 Bit
Interface Type
USB, Other, USB, RS232,KB
Optical Resolution
0.10mm (4mil)
Scan Speed
120 scans/sec.
Brand Name
OBM
Model Number
OBM-6802
Place of Origin
Guangdong, China
Features:
1.light and compact, fatigue released
2.good performance, accurate decoding
3.multiple built-in communication interfaces (KB,RS232,USB)
4.Impact-proof design to withstand multiple drops to concrete from 1.2m
| Specification | |||
| Aiming Light | 617 nm LED | ||
| illumination source | 6500K LEDs | ||
| scanning area | 39° (H) x 25° (V) | ||
| Roll(Till) | 0 - 360° | ||
| Elevation | ± 65° | ||
| Pitch | ± 60° | ||
| Exercise tolerance | Up to 25 in. / 63.5 cm per second | ||
| scanning rate | 30 fps | ||
| Print contrast | ≥ 25% | ||
| 1D | UPC/EAN, UPC/EAN with supplementals, BooklandEAN, ISSN, UCC Coupon Extended Code, Code128, GS1-128, ISBT 128, Code 39, Code 39 FullASCII, Trioptic Code 39, Code 32, Code 93, Code11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBarvariants, Korean 3 of 5, ISBT Concat | ||
| 2D | PDF417, MicroPDF417, Composite Codes, TLC-39,Data Matrix, Maxicode, QR Code, MicroQR, Aztec | ||
| Interface | USB: USB-HID Keyboard (default mode),COM Port Emulation. RS232:Standard | ||
| Operating Temperature | 0° - 50℃ | ||
| Storage Temperature | -40℃ - 70℃ | ||
| Operating Humidity | 5%~95% (non-condensing) | ||
| Storage Hunidity | 5%~95% (non-condensing) | ||
| Impact-Test | withstand multiple drops to concrete from 1.8M | ||
| Input-power | DC 5V,350mA | ||
| Lumination | Indoor:1600 Lux;Sunlight:86000 Lux | ||
| electrical safety | UL60950-1 2nd ed, CSA C22.2 No. 60950-1 2nd ed,EN60950-1/IEC60950-1 2nd ed. | ||
| EMI/RFI | FCC Part 15 Class B, ICES-003 Class B,EN55022 Class B, EN55024 | ||
| safety class | IP42 | ||
| Material | ABS+PC | ||
| Decode Range | |||
| Typical Performance* | Typical Working Ranges | ||
| HD Focus Range | |||
| Bar Code Type | Symbol Density | ||
| Code 39 | 5.0 mil | Near | Far |
| 100% UPCA | 13.0 mil | 30mm | 300mm |
| Code 39 | 20.0 mil | 35mm | 350mm |
| PDF 417 | 6.8 mil | 40mm | 130mm |
| Data Matrix | 10.0 mil | 30mm | 130mm |
| QR Code | 20.0 mil | 25mm | 250mm |
| Resolution 1D Code 39 | 4.8 mil (0.122mm) | ||
| Resolution 2D Data Matrix | 6.6 mil (0.168mm) | |
|
