Product
Thickness(mm)
Width(mm)
Length(mm)
Titanium sheet/plate
We are manufactory of titanium sheet,ASTM F67 Gr2 pure titanium sheet for surgical implantsproduce various grade and size of titanium sheet according to the requests of customers.
Chemistry Requirements:% Maximum unless given as a range/
Minimum Tensile Properties:
Titanium Sheet |
0.5-0.8 |
800 max, Ti 6Al-4V |
2000 max |
1000 max, CP Ti |
Titanium Sheet |
0.8-5 |
1000 max |
3000 max |
Titanium Plate |
5-8 |
2000 max |
4000 max |
Titanium Plate |
8-100 |
2500 max |
6000 max |
Product |
Thickness(inches) |
Width(inches) |
Length(inches) |
|||||||||||||
Titanium Sheet |
0.020"-0.032" |
31.5" max, Ti-6Al-4V |
78.7" max |
|||||||||||||
39.4" max, C.P. Ti | ||||||||||||||||
Titanium Sheet |
0.032"-0.20" |
39.4" max |
118.1" max |
|||||||||||||
Titanium Plate |
0.20"-0.32" |
78.7" max |
157.5" max |
|||||||||||||
Titanium Plate |
0.32"-3.94" |
78.7" max |
236.2" max |
|||||||||||||
Product |
Material |
Thickness |
Width |
Length |
||||||||||||
titanium Foil |
Gr1,Gr2,Gr3,Gr5 |
0.3mm-0.5mm |
400-600mm |
1500mm | ||||||||||||
|
Cold Rolling |
Hot Rolling |
||||||||||||||
Thickness |
0.3mm~4.0mm |
4.1mm~60mm |
||||||||||||||
Width |
1000mm max. |
3000mm max. |
||||||||||||||
Length |
3000mm max. |
4000mm max. |
||||||||||||||
Common Specification: |
Specification: |
Product Form |
||||||||||||||
|
ASTM B265(Gr2) |
Sheet,Strip and Plate |
||||||||||||||
ASTM B338 |
Tube,Seamless and Welded |
|||||||||||||||
ASTM B348(Gr2) |
Bars and Billets |
|||||||||||||||
ASTM B861 |
Seamless Pipe |
|||||||||||||||
ASTM B863 |
Wire |
|||||||||||||||
ASTM F67(Gr2) |
Unalloyed Titanium for Surgical Implants |
|||||||||||||||
N |
C |
H |
Fe |
O |
Residuals Each Max. |
Residuals Max.Total |
Ti |
|||||||||
0.03 |
0.08 |
0.015 |
0.3 |
0.25 |
0.1 |
0.4 |
Balance |
|||||||||
Condition |
UTS ksi (Mpa) |
0.2%YS ksi (Mpa) |
%EI. |
%RA* |
||||||||||||
As specified(shape) |
50(345) |
40(275) |
20 |
30 |
