Home > Products > titanium sheet > high quality best price for titanium coil
high quality best price for titanium coil
- 5000 Kilogram / Kilograms per Month
- shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Jiangsu, China | Application | industrial | |
| Thickness | 0.3-60.0mm | Width | 300~1219mm | |
| Length | 500~3000mm | Technique | Cold Rolled | |
| Grade | GR5 | Ti (Min) | 99% | |
| Brand Name | dongfu |
Product Description
7mm titanium sheet grade 5 /titanium medical grade plate
| Products Name: | Titanium alloy plate/sheet | |||
| Material: | Gr1, Gr2, Gr3, Gr4, Gr5, Gr6, Gr7, Gr9, Gr11, Gr12.. | |||
| Size: | Thk0.3~60mm *W 400~3000mm* Length1000~4000mm or customized size as drawing. | |||
| Standards | ASTM B265 | |||
| State: | M/Y/R/ST | |||
Processing: | Hot rolling, Cold rolling | |||
| Surface: | Bright, Polished, Pickling, Acid cleaning | |||
| Technic Test: | Tensile test, Visual, Ultrasonic, Macrostructure, Microstructure | |||
| Application: | Industrial, Chemical, Medical | |||
Chemical requirements:
Grade | Ti | Chemical composition | |||||||||
|
| Major composition | residual elements (not more than) | ||||||||
|
| Al | V | Sn | Mo | Pa | Fe | C | N | H | O |
Gr1ELI | Bal | / | / | / | / | / | 0.1 | 0.03 | 0.012 | 0.008 | 0.1 |
Gr1 | Bal | / | / | / | / | / | 0.2 | 0.08 | 0.03 | 0.015 | 0.18 |
Gr2 | Bal | / | / | / | / | / | 0.3 | 0.08 | 0.03 | 0.015 | 0.25 |
Gr3 | Bal | / | / | / | / | / | 0.3 | 0.08 | 0.05 | 0.015 | 0.35 |
Gr4 | Bal | / | / | / | / | / | 0.5 | 0.08 | 0.05 | 0.015 | 0.4 |
Gr5 | Bal | 5.5~6.75 | 3.5~4.5 | / | / | / | 0.3 | 0.08 | 0.05 | 0.015 | 0.2 |
Gr5ELI | Bal | 5.5~6.5 | 3.5~4.5 | / | / | / | 0.25 | 0.08 | 0.03 | 0.012 | 0.13 |
Physical properties:
Grade | Mechanical Properties (>%) | ||||||
Tensile Strengh (min) | Yield Strengh (0.2% offset) | Elongation (min %) | |||||
Ksi | Mpa | Min | Max |
| |||
Ksi | Mpa | Ksi | Mpa | ||||
Gr1 | 35 | 240 | 20 | 170 | 45 | 310 | 240 |
Gr2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
Gr3 | 65 | 450 | 55 | 380 | 80 | 550 | 18 |
Gr4 | 80 | 550 | 70 | 483 | 95 | 650 | 15 |
Gr5 | 130 | 895 | 120 | 828 | - | - | 10c |
Gr7 | 50 | 345 | 40 | 275 | 65 | 450 | 20 |
Gr9 | 90 | 620 | 70 | 483 | - | - | 15D |
Gr12 | 70 | 483 | 50 | 345 | - | - | 180 |
