Spring Steel Wire

Name: Spring Steel Wire
Brand: Huaxing
SKU: 124644537
Availability: InStock

US$ 677 - 1,777 MOQ: 5 Tons

Key Specifications

Steel Grade:

60# 65# 70# 72# 80#

Standard:

AISI, ASTM, GB, JIS

Wire Gauge:

0.2-13mm

Nantong Huaxing Steel Wire Products Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NANTONG OR SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Steel Grade 60# 65# 70# 72# 80#

Standard AISI, ASTM, GB, JIS

Wire Gauge 0.2-13mm

Place of Origin Jiangsu, China

Type Spring

Application Rope

Alloy Or Not Non-alloy

Special Use Cold Heading Steel

Model Number 0.2-13mm

Brand Name Huaxing

Specifications

1.Diameter range:0.2-13mm
2.Main application:making spring,mattress,wire rope.
3.Standard:GB4357,DIN17223,JIS G 3521

High Carbon Spring Steel Wire Performance:

1.Diameter range:0.2-13mm
2.Main application:making spring,mattress,wire rope.

3.Standard:GB4357,DIN17223,JIS G 3521

Standard:DIN17223:

High Carbon Spring Steel Wire
wire diameter(mm)	Tensile Strength(N/mm² )
wire diameter(mm)	Grade A	Grade B	Grade C
0.30		2370-2650
0.40		2270-2550
0.50		2200-2470
0.60		2140-2400
0.70		2090-2350
0.80		2050-2300
1.00	1720-1970	1980-2220
1.20	1670-1910	1920-2160
1.40	1620-1860	1870-2100
1.60	1590-1820	1830-2050
1.80	1500-1780	1790-2010
2.00	1520-1750	1760-1970	1980-2200
3.00	1410-1620	1630-1830	1840-2040
4.00	1320-1520	1530-1730	1740-1930
5.00	1260-1450	1460-1650	1660-1840
6.00	1210-1390	1400-1580	1590-1770
7.00	1160-1340	1350-1530	1540-1710
8.00	1120-1300	1310-1480	1490-1660
9.00	1090-1260	1270-1440	1450-1610
10.00	1060-1230	1240-1400	1410-1570
11.00		1210-1370	1380-1530
12.00		1180-1340	1350-1500
13.00		1160-1310	1320-1470
