Cheap Tilt Angle Sensor High Quality

The LCA328T series inclinometer which developed by Rion Company is a small volume MEMSdual-axis tilt sensor, because of built-in the latest MEMS production technology inclination unit, small size, long distance transmission can up to over 2000 Meters, strong ability of resisting external electromagnet interference, can be adapted to long-term working in the industry harsh environment.

This product adopts the non-contact measuring principle, can real-time output the current attitude angle, simple to use, no need to find the relative variation of the two surface for mounting. It is a ideal choice for Industrial automation control and platform measuring attitude !

Features:

Dual-Axis Inclinometer                                                   Measuring range±0°~±90° optional

Accuracy: refer to the technical data                            Wide voltage input: 9~36V

Output mode: 4~20mA                                                  Wide temperature working: -40~+85°C

IP67 protection class                                                     Highly anti-vibration performance >3500g

Resolution: 0.05°                                                           Small Volume : 55×37×24mm(customized)

Application:

Electric blind man chair leveling                                  Cloud deck operating monitor

Satellite antenna positioning                                       Medical equipment leveling

Car Chassis Measurement                                         Four - wheeled positioning system

engineering mechanical measurement of dip angle

Product Show

Parameter

Order Information

Dimension

Measuring Directions&Fix

The installation must guarantee the product bottom is parallel to measured face,and reduce the influence of dynamic and acceleration to the sensor. This product can be installed horizontally or mounted vertically (mounted vertically selection is only applicable to the single axis), for installation please refer to the following scheme.

Shenzhen RION, as a positon sensor manufacturer and solution expert, attaches much importance to products reseach and develop which spend over 20% of annual profit. We have the most R&D personnel and best technology comparing with our peer to raise our up on the high level of sensor field. And we orientate ourself to market tightly and engage ourself into providing the most considerate and professional solution and service to customers. RION introduce advanced equipment, such as TEMP&HUMI chamber, salt spray corrosion test chamber, high precision automatic turntable, high precision marble checking platform, digital thermostat drying oven, electrostatic discharge tester and 360 degree mechanical turntable etc, and set up Environmental Testing Laboratory, Product Aging Chamber, 2D&3D Posture Calibration Room and Shake&Impact Test Room for R&D and factory test.

Beside owning excellent hardware, RION also developed 15 sets of software independently and keep developing, including multi-sensor monitor software, remote sensor monitor software, synchronous dynamic l tracking 3D presentation software, tilt switch early warning and debugging software and sensor serial port setting presentation software etc which could apply to XP, Win7, Win8, WinCE and Android system. RION, owning talent and diligent personnel, advanced technology and market-orientated strategy, engages itself in offerring you the most considerate and professional solution and service of position sensor.

You satisfaction is our ultimate destiny.

Certificates & Honor

Packaging: carton with sponge

We will ship your order within 7 business days after we receive the full payment.

If you choose ship by DHL/UPS/FEDEX/TNT,it will take 3-5 work days; If you choose EMS ,it will take 5-7 work days.

One year warranty is provided, during that period, we exchange and fix the malfunction item forfree, and still we take care of products for its lifetime.

we are position sensor solution expert, full service and support before, in the middle of and after sales would be provided.

We accept the payment by Escrow/Alipay,including Paypal,Credit Card and T/T, WU.
