4 Axis Tilt Inclination Reminder Level Control Switch High Accuracy
SCA1900T is a dual axis inclinometer module with analog voltage output, adopts VTI MEMS control unit by measuring the static gravity field changes then convert into inclination change, the changes in mode output voltage (0-5V),mainly used to measure the inclination of the object with respect to the horizontal plane.Resolution is0.0025deg,accuracy specification please refer to the page 3 of product technical data .
This product uses non-contact measurement principle, can real-time output current posture inclination,Simple to use, and no need to retrieve the relative changed surface to install.Latest MEMS inclinometer productive technology production, high-precision, small size, strong resistance to external electromagnetic interference ability, the ability to withstand shock and vibration. It is the ideal choice for industrial equipment, platform measuring attitude!
Features
Dual-Axis Inclinometer(Single axis are optional) Measuring Range : ±1~±85°optional
Accuracy: refer to the technical data DC 5V voltage input
Output interface :0~5V Wide temperature working: -40~+85°C
Resolution: 0.0025° Small Volume : 30×30×5mm(customized)
Application:
Engineering vehicles automatic leveling Bridge & dam detection
Aerial platform vehicle,lifter safety & protection Medical facilities angle control
Underground drill posture navigation Shield pipe jacking application
Based on the angle direction measurement Geological equipment inclined monitoring
Directional satellite communications antenna pitching angle measurement
Ordering information:
Dimmension
Measuring Directions&Fix
Technical Data
RION Technology Co., Ltd. is located in a fantastic city - Shenzhen. Our company is a high technology company that integrates research, development, production and sale, and is mainly engaged in the sale of inclinometer sensors, digital compasses, digital dipmeters and acceleration sensors. These products are widely used in many industrial control fields, such as automobiles, ships, airplanes, railways, medical facilities, dam safety monitoring, oil drilling, coal mining and ocean surveying. Our company has established good business elationships with many international famous companies. We adhere to the service guideline of "Client-centered". "Client uppermost, credit first, service best" is our business philosophy.
Our company provides accurate, efficient, civilized and complete services for clients.
Let us provide you with the best products. To save purchasing cost and time, contact us now.
Certificates & Honor
Packaging: carton with sponge
We will ship your order within 7 business days after we receive the full payment.
If you choose ship by DHL/UPS/FEDEX/TNT,it will take 3-5 work days; If you choose EMS ,it will take 5-7 work days.
we are solution expert, we can make as your own design,shape,size,color and any other requirements.Any time when you received the goods,you will find them very personalized in the target market.
Being a professional manufacturer of tilt sensor, vibration sensor, compass etc, we will provide service and technical support before, in the middle of and after sales.
We accept the payment by Escrow/Alipay,including Paypal,Credit Card and T/T, WU.
