TL638D High Quality Three axis/ Tri-axial Current Type Electronic Gyroscope Sensor With Standard 4-20mA Output

2pcs/box, 50pcs/ctn

Specifications

1.High performance drift stability
2.Excellent vibration performance
3. 4-20mA Current output

TL638D High Quality Three axis/ Tri-axial Current Type Electronic Gyroscope Sensor With Standard 4-20mA Output











General Description :



TL618D is a gyroscope (angle rate sensor) based on the micro mechanical principle, a miniature inertial devices for mainly measuring the angular velocity of a moving object. Product internal with the silicon ultrafine precision ring sensing technology so that it has a high-performance, waterproof,anti-vibration, light weight, anti-electromagnetic interference characteristics and etc. Uninterrupted the machine with self-test technology, the filtering algorithm and the first time in the country by eliminating resonance technology to solve the influence on data because of the surrounding noise or vibration interference source to the ordinary gryoscope. TL618D add another international temperature sensor ompensation technology to solve the temperature drift impact problems,with over-temperature stability and long life characteristics etc. to realize the domestic similar products technology-leading technology.



Products with high cost-effective, small volume ,more advantages than the FOG in application fields, is now widely used in the automotive, military, marine, moving objects, position control & attitude control, and other applications that require precise angle measurement occasions !





Key Features :



• High performance drift stability
• Low noise
• Light weight
• Long life,strong stability
• Cost-effective
• Excellent vibration performance
• All solid state
• Compact & light design
• 4-20mA Current output
• Wide temperature range
• DC+9~36V power supply
• Temperature drift< ±0.2°/sec



Application:



• Military & Industry
• Navigation

• Car navigation
• Platform stability

• Auto safety system

• Remote control helicopters
• Turck-mounted satellite antenna equipment

• Industrial control
• Equipments
• GPS combination
• Camera stability
• Robot
• 3D virtual reality
• Ships electronic needle error compensation on inclined(angle rate)inductioni equipment











Our Company & Workshop View :







Certificates & Test Reports :





 We can offer :



•  Reliable high quality products and services
•  Perfect whole system application solution
•  Strong technical support before or after sales service
•  Extend strong sales teams & distributors global
•  OEM products as buyer's requests

 Our main products :



• Single/Dual-axis High accuracy Inclinometer (digital , current , voltage, CAN output type etc.  )
•  2D / 3D Electronic Compass Sensor (RS232, RS485,TTL output, etc.)
• 1-Axis , 2-Axis, 3-Axis Accelerometer (digital , current , voltage output, etc.)
• 1-Axis , 2-Axis, 3-Axis Gyroscope((digital , current , voltage output, etc.)
• Single /Dual / Three-Axis Angular Gyro Sensor (RS232, RS485,TTL output, etc.)
• High performance MEMS Mini AHRS ( Attitude Heading Reference System )
• Other Agent Products PNI...etc



Order Process :



Before order pls contact us for confirm detailed informaiton such as model ,price ,lead time ...etc .



Payment ways :

T/T, WU or Paypal;



Delivery methods & Time :



DHL takes 3-5days ,  Fedex takes 2-7 days , UPS takes 3-7day , EMS takes 10-25days ;



Quality Policy :



We gurantee 1 year in free charge .



Storage :Note usually we don't make any items in stock , samples customize time need around 3-7days .
