Chinese Manufacturer Price Digital Angle Meter Electronic Bevel Box Meter
General Description
DMI160 is a cost-effective 0.1deg digital display inclinometers (level) which launched by Rion company to customers who request a low cost, this product is for the first time using a combination of
mechanical and electronic principles ,mutual compensation angle during the measurement process , can play a mechanical principles accuracy and electronic principles stability, lead the international quality
boutique and build core technology trend.When the ordinary digital display inclinometer measuring the X-axis, if Y-axis tilt angle change occurs then easily influence X axis , and most manufacturers state san meet 0.1 ° accuracy indicators, but the actual full scale measurement process can not guarantee 0.1 °, this product to solve these two problems, when the mechanical inclination unit measuring the X-axis, Y-axis electronic inclination unit make compensation, to ensure the stability of its data, and can do 0 ~ 180 °, full scale measurement and 0.1 °stable accuracy. ALso the DMI160RealStar digital display inclinometer can be separated with the tilt sensor for using , remote monitoring the angle changes via cable , cost-effective, small volume, easy to carry, the product comes with a strong magnetic force for installation method , is particularly suitable for
the measurement of the construction and mechanical installation!
Features :
- Accuracy:0.1°
- Repeatability:0.1°
- Angle data response fast
- Switch between relativity and absoluteness
- Working temperature 0°~ +45°C
- Angle compensation function
- Measuring range :90°x 4 = 360
- Power supply :3V Lithium battery
- With number hold function, convenient for record
Application:
- Building operations
- Vehicle maintenance
- Road grade
- Machinery installation
- Pipe installation
- Industry platform
Technical Data
Measuring range |
0~360 |
° |
Measuring accuracy |
±0.1 ° (0°,90°,180°,270°) ±0.2 °< other angle |
° |
Working Temperature |
0°~ +45°C |
°/°C |
Working current |
<100 |
uA |
Working humidity |
85 |
%RH |
Display resolution |
0.1 |
° |
ZERO Temperature drift |
0.05 to 0.005%F.S/°C |
%F.S/°C |
Power |
AAA battery |
V |
Power consumption |
<100 |
mW |
Dimension |
L50mm*W50mm*H32mm |
mm |
Products show
Measurement Direction
Product Function Introduction
