Specifications
LCA316 single axis inclinometer1.Single-axis digital-type
2.Long term stability<0.1degree
3.IP65
single axis inclinometer sensor
General Description
LCA316Tseries products which launched by RION company is a new generation digital type small size MEMS inclinometer, Built-in gravity tilt unit, by measuring the static gravity acceleration then convert into the inclination change. Thus can measure the inclinometer output relative to the horizontal tilt or pitch tilt. Output RS232, RS485 or TTL level interface standard optional. Because of built-in MCU control system, that make the sensor output linearity get two amendments, made up the analog type precision drop because of insufficient correction led to .
This product adopts the non-contact measuring principle, can real-time output the current attitude angle, simple to use, no need to find the relative variation of the two surface for mounting. It is a ideal choice for Industrial automation control and platform measuring attitude,strong ability of resisting external electromagnet interference, can be adapted to long-term working in the industry harsh environment. This product is suitable for the static and slow changes dynamic measurement, not suitable for rapid changes dynamic measuring.
Features:
1.Single-Axis Inclinometer
2.Measuring Range : ±10~±90° optional
3.Long-term stability 0.2 °
4.DC+5V input
5.Output mode RS232/RS485/TTL (optional)
6.Wide temperature working: -40~+85°C
7.IP67 protection class
8.Highly anti-vibration performance >3500g
9.Resolution: 0.05°
10.Small size : 55×37×24mm(customized)
Application:
1.Electric blind man chair leveling
2.Cloud deck operating monitor
3.Satellite antenna positioning
4. Medical equipment leveling
5.Car Chassis Measurement
6.Four - wheeled positioning system
ing mechanical measurement of dip angle
Technical Data
| Parameters Conditions LCA316T-30 LCA316T-60 LCA316T-90 LCA316T-360 unit |
Measuring range |
| ±30 | ±60 | ±90 | ±180 | ° |
Measuring axis |
| X | X | X | X |
|
Resolution |
| 0.05 | 0.05 | 0.05 | 0.05 | ° |
Absolute accuracy |
| 0.1 | 0.1 | 0.2 | 0.2 | ° |
Long term stability |
| 0.2 | 0.2 | 0.25 | 0.25 |
|
Zero temperature coefficient | -40~85° | ±0.008 | ±0.008 | ±0.008 | ±0.008 | °/°C |
Sensitivity temperature coefficient | -40~85° | ≤150 | ≤150 | ≤150 | ≤150 | ppm/°C |
Power on time |
| 0.5 | 0.5 | 0.5 | 0.5 | S |
Response time |
| 0.05 | 0.05 | 0.05 | 0.05 | s |
Output rate | 5Hz,15Hz,35Hz,50Hz can be setting | |||||
Output signal | RS232/RS485/RS422/TTL/PWM/CAN/MODBUS can be customized | |||||
EMC | According to EN61000 and GBT17626 | |||||
MTBF | ≥45000 hours/times | |||||
Insulation Resistance | ≥100M | |||||
Shockproof | 100g@11ms,3Times/Axis(half sinusoid)) | |||||
Anti-vibration | 10grms,10~1000Hz | |||||
Protection glass | IP67 | |||||
Cables | Standard 1M length,wearproof,grease proofing,wide temperature, Shielded cables 4*0.4mm2 | |||||
Weight | 90g(without cable) | |||||
*This Technical data only list ± 30 °, ± 60 °, ± 90 °, ± 360 ° series for reference, other measuring range please refer to the adjacent parameters.
