Hot selling and high quality Guoshun heat resistant and fiberglass woven tape
Description:
Heat resistant and fiberglass woven tape is made of glass fiber yarns, of which the alkali metal is less than 0.8%. Heat resistant and fiberglass woven tape is weaved by non-alkali fiberglass yarn.
Heat resistant and fiberglass woven tape has good thermal resistant and insulation features. Heat resistant and fiberglass woven tape is widely used for windings of motor and transformer
Application:
Heat resistant and fiberglass woven tape is widely used for electric motors,coil of transformers as insulating binding materials.
Characteristics
Heat resistant and fiberglass woven tape has good thermal resistance
Heat resistant and fiberglass woven tape has good excellent insulating
Heat resistant and fiberglass woven tape has good corrosion resistance
Good corrosion resistance Types
| Type | Impregnating Compound | Application Domain | Application |
| The general | Olefin or silicane | Dry type transformer, arrester, Generator, cable, electric appliance and glass fiber reinforces plastic |
Filler or banding material |
| The reinforcing (bulked yard) |
Olefin or silicane | Architecture or electric | Fireproofing; High temperature resistant Airproof material |
Specification and Property
| Code | Thickness(mm) | Width(mm) | Breakdown Strength≥n/10mm | Texture | Roll Length(m) | Comment |
| ET-60 | 0.06±0.005 | 10-30 | 100 | Tabby | 200 | The general |
| ET-80 | 0.08±0.01 | 10-30 | 150 | Tabby | 200 | |
| ET-100 | 0.10±0.01 | 10-80 | 200 | Tabby/ Cheveron | 50 | |
| ET-130 | 0.13±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-150 | 0.15±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-160 | 0.16±0.02 | 10-255 | 300 | Tabby/ Cheveron | 50-200 | |
| ET-200 | 0.20±0.02 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-250 | 0.25±0.025 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-300 | 0.30±0.03 | 10-255 | 400 | Tabby/ Cheveron | 50-200 | |
| ET-1500 | 1.5±0.15 | 10-155 | Temperature Tolerance is 800 ℃ |
Tabby/ Cheveron | 30 | |
| ET-2000 | 2.0±0.20 | 10-155 | Tabby | 30 | The reinforcing | |
| ET-2500 | 2.5±0.25 | 10-155 | Tabby | 30 | ||
| ET-3000 | 3.0±0.30 | 10-155 | Tabby | 30 | ||
| Bulked yarn | Diameter:5,6,7,10(mm) | Knit | 50/100 |
|||
