Specifications
1. We are engaged in insulating material has been 20 years2.There are over 300 factories use our products.
China supply e glass fiberglass tape
Description:
High Quality supply fiberglass tape is made of glass fiber yarns, of which the alkali metal is less than 0.8%. High Quality supply fiberglass tape is weaved by non-alkali fiberglass yarn.
High Quality supply fiberglass tape has good thermal resistant and insulation features. High Quality supply fiberglass tape is widely used for windings of motor and transformer
Application:
High Quality supply fiberglass tape is widely used for electric motors,coil of transformers as insulating binding materials.
Characteristics
High Quality supply fiberglass tape has good thermal resistance
High Quality supply fiberglass tape has good excellent insulating
High Quality supply fiberglass tape has good corrosion resistance
Good corrosion resistance Types
| Type | Impregnating Compound | Application Domain | Application |
| The general | Olefin or silicane | Dry type transformer, arrester, Generator, cable, electric appliance and glass fiber reinforces plastic |
Filler or banding material |
| The reinforcing (bulked yard) |
Olefin or silicane | Architecture or electric | Fireproofing; High temperature resistant Airproof material |
Specification and Property
| Code | Thickness(mm) | Width(mm) | Breakdown Strength≥n/10mm | Texture | Roll Length(m) | Comment |
| ET-60 | 0.06±0.005 | 10-30 | 100 | Tabby | 200 | The general |
| ET-80 | 0.08±0.01 | 10-30 | 150 | Tabby | 200 | |
| ET-100 | 0.10±0.01 | 10-80 | 200 | Tabby/ Cheveron | 50 | |
| ET-130 | 0.13±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-150 | 0.15±0.015 | 10-255 | 250 | Tabby/ Cheveron | 50-200 | |
| ET-160 | 0.16±0.02 | 10-255 | 300 | Tabby/ Cheveron | 50-200 | |
| ET-200 | 0.20±0.02 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-250 | 0.25±0.025 | 10-255 | 350 | Tabby/ Cheveron | 50-200 | |
| ET-300 | 0.30±0.03 | 10-255 | 400 | Tabby/ Cheveron | 50-200 | |
| ET-1500 | 1.5±0.15 | 10-155 | Temperature Tolerance is 800 ℃ |
Tabby/ Cheveron | 30 | |
| ET-2000 | 2.0±0.20 | 10-155 | Tabby | 30 | The reinforcing | |
| ET-2500 | 2.5±0.25 | 10-155 | Tabby | 30 | ||
| ET-3000 | 3.0±0.30 | 10-155 | Tabby | 30 | ||
| Bulked yarn | Diameter:5,6,7,10(mm) | Knit | 50/100 |
|||
