Home > Products > wire packing machine > Steel Wire Rod Wrapping Machine XH-1000

Steel Wire Rod Wrapping Machine XH-1000

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Other, Machinery & Hardware
Packaging Type	Other	Packaging Material	Plastic
Automatic Grade	Automatic	Driven Type	Electric
Voltage	according to customers' demands	Power	3.75kw
Place of Origin	Jiangsu, China	Brand Name	Sanlian
Model Number	XH1000	Dimension(LWH)	202014502040(mm)
Weight	about 1450kg	Certification	ISO9001:2008
After-sales Service Provided	Engineers available to service machinery overseas

steel wire rod wrapping machine XH-1000

Detailed Selling Lead Description

Product Name: steel wire coil wrapping machine XH-1000

Company Published: 2002

Business Type: Manufacturer

Number Of Employees: 100-200 people

Place Of Origin: Jiangyin, Jiangsu, China

Port: Shanghai

Package: wooden case

Delivery Time: 30 days

Feature: Applicable for galvanized steel wire & stainless steel wire.The finished products will be packaged in loops, work automatically.

Main technical parameter:

Parameter name	Data
Rotor speed of packing ring	88R/min
Rotor speed of supporting roller	3.56-20.88R/min
Width of packing strap	90mm
Outer diameter of packing strap	500mm
Inner diameter of packing strap paper tube	48mm
Lap width ration	Changeable
Being packed dimensions	Max. outer diameter	1000mm
	Min. inner diameter	300mm
	Max. width	350mm
	Max. weight	500kg
Total Power	3.75kw
External dimension	LengthHeightWidth	202014502040(mm)
Machine weight about 1450kg

Pictures of XH-1000 wire packing machine:
