CO2 gas shielded welding wire drawing machine
- 6 Set / Sets per Month
- shanghai
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | sanlian | Model Number: | LZ7/600+LZ7/400 |
Usage: | Drawing |
Product Description
CO2 gas shielded welding wire production line processing flow:
1.pretreatment rough drawing line
n material ER50-6 high line tray, standard 5.5mm
n steel wire pretreatment:
Up-draft pay-off stand + wire-break stop device + mechanical descaling devic(including water washing) + electrical analysis acid water washing + Boron coatingting device + Super audio drying + cooling wind tube blowing + LW/600 pulley style wire drawing machine + LZ5/600 or LZ6/600 straight line wire drawing machine group + SG800 H-wheel take up machine
2.Fine drawing production line
FX800 H-wheel pay-off machine + LZ8/400(or LZ7/400) straight line wire drawing group + tension bracket + washing bath + SG630 H-wheel take up machine
3.chemically copper plating production line
FX630 pay off machine + self adjust tension pay off bracket + steel wire hold roller turnaround bracket + hot washing + electrical analysis alkaline washing bath + hot water washing after alkaline + electrical analysis acid washing bath + washing activation bath + chemically plating bath + washing + neutralization washing + hot water washing + drying (electric heating or steam heating) + turnaround bracket + dragging pulling polishing machine + SG630 H-wheel take up machine
4.layer wrapping package production line
SG630 H-wheel pay off machine (initiative pay off style ) + middle machine + layer wrapping
5.S4525 hot shrink package machine to have packaging ,put in storage
6.LZ7-600 welding wire drawing machine
lz7/400 welding wire drawing machine:
No. | Item | Unit | Data |
1 | Machine type |
| LZ7/400 |
2 | Tuning type |
| Straight line tuning |
3 | Drawing passes |
| 7 |
4 | Block diameter | mm | Φ400 |
5 | Speed adjustable mode |
| AC freq. Con. Speed Adjustable |
6 | Motor power | KW | 7×11 |
7 | Motor Brand |
| HENGDA |
8 | Inlet diameter | mm | Max Φ2.2 |
9 | Outlet diameter | mm | Min Φ0.9 |
10 | Total compression | % | 83.2% |
11 | Average compression | % | 22.5% |
12 | Drawing speed | m/s | Design Max.speed:22m/s; |
13 | Control mode |
| Fully digital |
14 | Logical control |
| PLC (SIEMENTS) |
15 | Converter |
| Schneider |
16 | Touch screen |
| SIEMENS |
17 | Wire-in strength | MPa | ≤700 |
18 | Carbon content in material |
| low carbon (≤0.25%) |
19 | Block cooling |
| "Narrow Gap" water cooling ; Forced Air Cooling |
20 | Die box |
| Direct water cooling |
21 | Water pressure |
| 0.2~0.3Mpa |
22 | Rolling bearing |
| SKF |
23 | Air pressure & Water pressure |
| ≥0.5Mpa ; 0.2-0.3MPa |
24 | Braking time | S | Normal stop≤50s,EMG stop≤5s |
7. Pictures of straight wire drawing machine:
8.About us:
(1). We are one of the leading wire drawing machine manufacturers with more than 20 years experiences with a high reputation.
(2). We have gotten ISO9001:2008 standard and certificate.
(3). Company location: Jiangyin city, 150km away from Shanghai. Welcome to visit us, we will pick you up from Shanghai.
(4). Number of employees: 100-120
(5). We have a professional technical team, a good after-sale service team, an excellent production management team.
(6). We can design and produce various wire drawing machines, auxiliary equipment according to customers’ special requirements.
