CATV male F terminator
- 100000 Piece / Pieces per Month
- Shanghai
- T/T D/P D/A Credit Card
Product Details
Place of Origin: | Jiangsu, China | Brand Name: | Dongbei | Model Number: | OPT |
Type: | F | Application: | RF | Gender: | Male |
Product Description
Specifications
F terminator1.brass with nickle plating
2.High return loss
3.prevent signal ingress and egress
Connector type | F-male 3/8-32 UNEF | Working Voltage | 170V max |
Frequency Range | DC~1GHz | Vibration | 100m/s2 (10~500Hz) |
Impedance | 75Ω | Temp.range | -25~+60°C |
Conductor resistance | Internal 6miliohms max | Material | Shell:Copper, nickel plating |
External 1 miliohms max | Nut:Copper, nickel plating | ||
Insulating resistance | ≥ 1000 MΩ@ DC500V | O ring:Silicon rubber | |
Withstanding voltage | 750V rms | Applicable standard | IEC 60169-24 |
- Used to terminate unused ports reducing reflections
- Versions available to meet every requirement
- Precision high return loss version ensures the most consistent impedance match possible
- Prevents signal ingress and egress
- Reduces water migration into open port
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive
