CATV Aluminium ks Port Terminator

FOB Price

Negotiable / Piece

2000 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

ks port terminator
1) Wide bandwidth for use in broadband systems
2)O ring sealed watertight
3) ROSH,SGS

Connector type	5/8	Vibration	100m/s2 (10~500Hz)
Frequency Range	DC~1GHz	Durability(mating)	≥500(cycles)
Impedance	75Ω	Temp.range	-25~+60°C
Insertion Loss	< 0.3dB	Material	Shell : Aluminium
Power Capacity	> 20 A		Conductor: Brass,silver plating
Conductor resistance	Internal ≤ 10 mΩ		Conductor: Brass,silver plating
Conductor resistance	External ≤ 5 mΩ		Insulator: PTFE
Insulating resistance	≥ 1000 MΩ @DC500V		O Ring: Silicon Rubber
Withstanding voltage	170V max	Applicable standard	IEC 60169-24

Port terminators provide a 75 Ohm match to unused KS entry ports
Wide bandwidth for use in broadband systems
Standard pin length accommodates all amplifer and multitap mating requirements
High return loss for excellent digital signal performance
Superior power capability provides a minimum of 20 Amps current capacity on all connectors and adapters
O-ring sealed for maximum enviromental protection,eliminating water migration
