Help CenterHardline Outdoor 2 Way CATV Tap
Related Products
-
1 GHz Hard Line Catv Directional CouplerNegotiableMOQ: 200 Pieces -
1 GHz Hard Line Directional Outdoor Catv CouplerNegotiableMOQ: 200 Pieces
-
3way CATV Outdoor Splitter /tapNegotiableMOQ: 100 Pieces
-
Catv 8 Way Tap and SplitterNegotiableMOQ: 400 Pieces
-
Outdoor CATV Splitter 3 Output 6 dBNegotiableMOQ: 400 Pieces
Specifications
Catv tap1)Aluminum alloy housing
2) 5~1000 Mhz
3)Current Capacity; 10Amps,60VAC
- Standard housing for 2ports devices
- Aluminum alloy housing
- Neoprene weather gasket
- Double polyurethane coating
- RF interference gasket
- Rotational seizure mechanism for areal or pedestal installation
- Uninterrupted power and RF passing connector
Item |
4-way Tap |
||||||||
|
Tap Loss (dB) |
Model |
10 |
12 |
14 |
16 |
18 |
20 |
||
Tap Loss Deviation |
15——65MHz |
±1.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
20.0 |
|
65——550MHz |
±1.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
20.0 |
||
550——750MHz |
±1.7 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
20.0 |
||
750——1000MHz |
±2.0 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
20.0 |
||
|
Insertion Loss (dB) |
15——65MHz |
≤4.0 |
≤4.0 |
≤4.0 |
≤3.5 |
≤3.0 |
≤3.0 |
||
65——550MHz |
≤4.8 |
≤4.5 |
≤4.0 |
≤3.5 |
≤3.5 |
≤2.8 |
|||
550——750MHz |
≤5.5 |
≤5.0 |
≤4.5 |
≤3.8 |
≤3.8 |
≤3.0 |
|||
750——10000MHz |
≤6.0 |
≤5.5 |
≤5.0 |
≤4.5 |
≤4.0 |
≤3.5 |
|||
|
Reverse Isolation (dB) |
15——65MHz |
≥18 |
≥18 |
≥18 |
|||||
65——550MHz |
≥21.5 |
≥22 |
≥23 |
||||||
550——750MHz |
≥21 |
≥21 |
≥22 |
||||||
750——10000MHz |
≥20 |
≥20 |
≥20 |
||||||
Mutual Isolation (dB) |
15——65MHz |
≥18 |
|||||||
65——550MHz |
≥23 |
||||||||
550——750MHz |
≥21 |
||||||||
750——10000MHz |
≥20 |
||||||||
Return Loss (dB) |
15——65MHz |
≥10 |
|||||||
65——1000MHz |
≥14 |
||||||||
