1 GHz Hard Line Catv directional coupler
- 10000 Piece / Pieces per Month
- Shanghai
- D/P D/A Credit Card
- In stock PJ-208B earphone audio socket 4-pin 2.5 plug earphone socket plastic plug
- In stock PJ-208A earphone audio socket 4-pin 2.5 plug-in anti wolf alarm plug
- simar popular 22/24 inch self-reversing monitor tempered glass mirror presidential conference meeting speech teleprompter
- simar Best selling 20/22/24/27/32 inch self-reversing flip monitor M-ZYS20/22/24/27/32 teleprompter
- 17/20/22/24/27/32 inch Broadcasting studio prompter teleprompter for recording
- NIORFNIO T50M 50W FM transmitter, high-power USB playback farm application 5-kilometer range
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | DB | Model Number: | OP1112A |
Product Description
Specifications
catv directional coupler1)Good frequency reaction characteristics
2)Small insertion loss
3)Find DC performance
- 5MHz to 1000MHz bandwidth capacity
- Aluminum alloy housing
- Neoprene weather gasket
- Double polyurethane coating
- RF interference gasket
- Output legs have shorting bars to disable power
- Rotational seizure mechanism for aerial or pedestal installation
- Power rating: 15 Amps, 60-90 Volts AC/DC, 1-60 Hz
- Dimensions: 6.0” wide, 5.0” high, 3.0” deep
DESCRIPTION | 1GHZ DIRECTIONAL COUPLER: 8dB,12dB,16dB (SHDC) | |||||||
1GHZ SPLITTER: 2 way Splitter,3-way Splitter (SHSP) | ||||||||
1GHZ LINE POWER INSERTER: SPI (SHPI) 15A | ||||||||
f(MHZ) | SHDC-8 | SHDC-12 | SHDC-16 | SHSP-2 | SHSP-3B | SHSP-3 | SHP-1 | |
Tap Loss | 5-40 | 8±1.5 | 11±1.5 | 15±1.5 | ||||
41-750 | 8±1.5 | 12±1.5 | 16±1.5 | |||||
751-1000 | 8±1.5 | 12.5±1.5 | 16±1.5 | |||||
INSERTION | 5.0-15 | 2.1 | 1.2 | 1.0 | 4±1.5 | 6.5 | 4.4/7.4 | 0.8 |
LOSS | 16-40 | 2.1 | 1.2 | 1.0 | 4±1.5 | 6.3 | 4.3/7.4 | 0.8 |
DB MAX | 41-250 | 2.1 | 1.2 | 1.2 | 4±1.5 | 6.3 | 4.3/7.5 | 0.8 |
(IN-OUT) | 251-450 | 2.1 | 1.4 | 1.2 | 4±1.5 | 6.5 | 4.3/7.5 | 0.8 |
451-550 | 2.1 | 1.4 | 1.2 | 4±1.5 | 6.8 | 4.3/7.8 | 0.8 | |
551-750 | 2.5 | 1.8 | 1.6 | 4±1.5 | 7.1 | 4.8/8.4 | 1.2 | |
751-900 | 3.0 | 2.0 | 1.6 | 4±1.5 | 7.8 | 5.2/8.8 | 1.2 | |
901-1000 | 3.2 | 2.2 | 1.8 | 4±1.5 | 8.1 | 5.5/9.3 | 1.2 | |
ISOLATION | 5.0-15 | 18 | 20 | 20 | ||||
DB MIN | 16-40 | 25 | 26 | 26 | ||||
(OUT-TAP) | 41-250 | 25 | 26 | 26 | ||||
251-450 | 25 | 26 | 26 | |||||
451-550 | 25 | 26 | 26 | |||||
551-750 | 22 | 22 | 22 | |||||
751-900 | 20 | 20 | 20 | |||||
901-1000 | 20 | 22 | 23 | |||||
ISOLATION | 5.0-15 | 18 | 20 | 20 | 65 | |||
DB MIN | 16-40 | 25 | 24 | 25 | 61 | |||
(TAP-TAP) | 41-250 | 25 | 24 | 25 | 61 | |||
(OUT-OUT) | 251-450 | 25 | 24 | 25 | 61 | |||
451-550 | 25 | 24 | 25 | 61 | ||||
551-750 | 22 | 24 | 22 | 58 | ||||
751-900 | 22 | 22 | 22 | 53 | ||||
901-1000 | 20 | 20 | 20 | 50 | ||||
RETURN | 5.0-15 | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
LOSS | 16-40 | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
DB MIN | 41-250 | 18 | 18 | 18 | 18 | 18 | 18 | 18 |
(ALL PORTS) | 251-450 | 17 | 17 | 17 | 17 | 17 | 17 | 17 |
451-550 | 17 | 17 | 17 | 17 | 17 | 17 | 17 | |
551-750 | 16 | 16 | 16 | 17 | 17 | 17 | 17 | |
751-900 | 16 | 16 | 16 | 16 | 16 | 16 | 16 | |
901-1000 | 16 | 16 | 16 | 16 | 16 | 16 | 16 |
