Home > Products > RF connector > Coaxial Connector - Mcx Connector for Rg174 Cable
Coaxial Connector - Mcx Connector for Rg174 Cable
- Shanghai
- T/T D/P D/A Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Dongbei | |
| Model Number | db-055 | Type | MCX | |
| Application | RF | Gender | Male |
Product Description
Specifications
rf coaxial connector - mcx connector1) brass with golden plated
2)connectors for flexible cable
3) small installed space

coaxial connector - mcx connector for rg174 cable
| Connector type | coaxial connector - mcx connector | Working Voltage | 335V max |
| Frequency Range | 0-6GHz | vswr | 1.2 max |
| Impedance | 50Ω | Temp.range | -65~+155°C |
| Conductor resistance | Internal ≤ 5mΩ | Material | Shell:brass, gold plated |
| External ≤ 2.5mΩ | Nut:brass, gold plated | ||
| Insulating resistance | ≥ 1000 MΩ | pin:brass,gold plated | |
| Withstanding voltage | 750V rms | Usability | 500 Cycles min |
- Manfactured of high quality brass with nickel plating of superior protection against v-corrosion
- Accommodates a wide range of medium to miniature-sized RG coaxial cables in a rugged medium-sized design
- Meets many customer application demands with plug styles available in straight and right angle and jack styles available in panel mount, bulkhead mount, and receptacle
our main market: north America South America Eastern Europe
Southeast Asia Africa Oceania
Mid East Eastern Asia Western Europe
Central America Southern Europe South Asia
PS:
- OEM are welcome
- high quality but low price
- We have many types connector for your choosing, if you have any query please fell free to contact me, I am glad service for you
- We have professional team to service for you, please tell me your detail information then I will offer you the right products you need
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive
Contact Us
- Yangzhou Dongbei Electronic Equipment Factory
- Contact nameDonald Chen Chat Now
- Phone86-571-81110240
- AddressHongyang West Road, Touqiao Town, Guangling Dist., Yangzhou, Jiangsu, China
