Specifications
smb high power rf connectors1.Watertight
2.50 ohm For RG8/ RG58 Cable
3.OEM accepted
smb high power 75ohm rf coaxial connectors pcb
We have various types connector and an professional ,experienced service team.
welcome to login our website check more products information.
and looking forward your inquiry,we will be glad to quote for you !
Connector type | smb male rf connector | Working Voltage | 335V max | |
Frequency Range | 0~4GHz (50Ω ) | vswr | max 1.30 | |
0~2GHz(75Ω) | ||||
Impedance | 50Ω | Temp.range | -65~+165°C | |
Conductor resistance | Internal ≤ 6mΩ | Material | Shell:brass, gold plating | |
External ≤ 1mΩ | male center contacts:brass, gold plating | |||
Insulating resistance | ≥ 1000 MΩ | female center contacts: Berylliumcopper,gold plating | ||
Withstanding voltage | 750V rms | Applicable standard | IEC 60169-24 | |
Advantage | |
1 | High quality.Strict quality control system, advanced quality inspection center and norms to ensure our products with excellent quality. |
2 | Competitive price. Companies to implement strict cost control, so we can maximize the lower production costs, the most favorable prices available for you. |
3 | Extensive production experiences. Our factory has been more than fifteen years of history, during which our factory has accumulated rich production experience. |
4 | Quick and flexible customization capability. Our factory has separated sample making room , so you just need to give us your sample or idea then you can receive the actual sample you want. |
SMB is one kind of low power miniature RF coaxial connectors with snap-on coupling mechanism. The characteristic of connectors is in small volume, light weight, excellent electrical performance, easy to use. They’re widely used in connection with RF coaxial cable in RF circuit of radio communication, test instruments, meter, radio station, TV station, the base station of the microwave system.
Information to customer
1.We highly appreciate your any enquiry by email, fax or instant message.
2.We will reply your email or fax within 12 hours.
3.Please fell free to call us at any time if there is any questions
why do you choose us?
We Consider Our Customers as Our Friends and Families, and We do Believe in the Win-Win Situation for Building up Long-Term Relationship.
- speciality
DongBei Electronic Element Factory, founded in 1995, is specilized in the design and manufacture of CATV connectors, electronic connectors, wireless connectors and cable assemblies.
- Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
- Innovation
Provide innovative,stable products and services.
- Customer Satisfaction
Anticipate cusomer needs and exceed their expectations.
