RF Gold Plating Right Angle PCB SMA Connector

Name: RF Gold Plating Right Angle PCB SMA Connector
Brand: DongBei
SKU: 124548863
Availability: InStock

Negotiable MOQ: 5000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

DongBei

Model Number:

PCB

Yangzhou Dongbei Electronic Equipment Factory

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name DongBei

Model Number PCB

Type F

Application RF

RF gold plating right angle SMA PCB Connector

Type SMA is one kind of RF coaxial connectors that is widely applied, with small-sized thread coupling
The characteristic of connectors is in wide frequency range, excellent performance, high reliability.
They are used in connection with RF cable or micro-strip line in RF circuit of the WLAN system, controlled program, microwave equipment and digital communication system.
The frequency can be up to 18GHz by using semi-rigid or semi-flex cable.

Radio Frequency (RF) connectors:

♥ MMCX, MCX, SMA, SSMB, SMB, BNC, TNC, N,.F CONNECTOR

♥ RF Connectors division of RF Industries designs and manufactures an extensive line of radio frequency

♥ (RF) coaxial connectors used in wireless telecommunications applications,

♥ including WiFi, PCS, radio,computer networks, test instruments and antenna devices.

High quality SMA male connector for use with TriLan 240 .

The connector can be used up to 6 GHz.

It features low insertion loss and high return loss.

5-6 GHz systems require specially designed quality connectors

that ensure optimal parameters.

Connector type	SMA connector	Insertion Loss	dB maximum = .03√[f(GHz)]
Frequency Range	.141" & .085" semi-rigid cable: 0-18 GHz Flexible cables: 0-12.44GHz	RF Leakage	-60 dB minimum
Impedance	50 Ω	Connector Affixment to Cable	Crimp and solder types
Contact Resistance	Inner contact: max 6 mΩ	Material	Shell: Brass
	Inner contact: max 6 mΩ		Shell: Brass
	Outer contact: max 2 mΩ		Contacts:Beryllium copper
Insulating resistance	5,000 MΩ minimum		Gaskets: Silicone rubber
Withstanding voltage	.141" & RG-58 Cables: 1,000 VRMS .085" & RG-316 Cables: 750 VRMS	Temperature Range	- 65°C to +165°C
Withstanding voltage		Temperature Range	- 65°C to +165°C
