Help CenterMagnetic Proximity Sensor,two Wire Door Sensor,automatic Door Sensor
Related Products
-
Door Sensor,electronic Door Sensor,door Proximity SensorUS$ 3.42 - 4.24MOQ: 1 Piece -
Thru Beam Door Magnetic Switch FMC01US$ 2.8 - 4.5MOQ: 1 Piece
-
FD Series NPN NO Magnetic Switch Sensor With CE Certificate Quality ChoiceUS$ 2.82 - 4.66MOQ: 5 Pieces
-
FD-11R 5-120VAC Reed Pipe Magnetic SwitchUS$ 2.2 - 3.62MOQ: 5 Pieces
-
CE Certificate Normal Open 12-24 VDC Magnetic Switch for CylinderUS$ 2.35 - 3.88MOQ: 5 Pieces
Product display
Specification
| Model | FMC01 | |||
| Output type | Normally open NPN | |||
| Sensing type | There reed tube contacts | |||
| Voltage range | 5~12VDC/AC | |||
| Maximun switching current | 100mA Max | |||
| Maximun contact capacity | 3.5W Max | |||
| Internal current capacity | no | |||
| Residual pressure drop | 2.5V Max.@10mA DC | |||
| Leakage current | no | |||
| Indicator | Red LED | |||
| cable | φ2.8,2C/oil resistant gray PVC | |||
| Maximum swithcing frequency | 1000Hz | |||
| Operating temperature range | -10°C~70°C | |||
| Impact resistance | 30G | |||
| Vibration resistance | 9G | |||
| Waterproof degree | IP67 | |||
| Protection circuit | no |
|||
Dimension drawing
magnetic proximity sensor,two wire door sensor,automatic door sensor
Certifications
More product
Our services
1.Prompt reply to our customer, we have to reply all the email within 24hrs.
2.Provide free replacement if there is any quality problem with our product.
3. Accept OEM Order, Ship the product with your logo.
Enterprise profile
F&C main product include fiber optic amplifier , fiber optic sensor, fiber optic lens, proximity sensor, photoelectric sensor, label sensor, light curtain, laser alignment, pressure sensor,magnetic sensor, M8 M12 female connector, laser sensor, color sensor,rail power supply,solid state relay.
F&C Technology has been making continuous breakthrough in new technology and new material application,. Our Target is “What you need can be found in F&C Sensing Technology”.
Packaging&Shipping
1.We will ship our product aboard with standard export package.
2.For small Qty, We will Ship our product to you by express.
3.For mass production , We will ship our product to you by Air or sea.
