Dongbei Compression 75 Ohms Bnc Connector for tv Antenna

Name: Dongbei Compression 75 Ohms Bnc Connector for tv Antenna
Brand: DB Connector
Availability: InStock

FOB Price

US$ 0.2 - 0.3 / Piece

2000 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	DB Connector
Model Number	OPT-BNC-1	Type	Other, BNC, Male to male/female
Application	Other, RF, Adapter(Communication)	Gender	Male

Coaxial cable bnc connector for tv antenna

Name	BNC connector for RG-6 RG59
Code	Opt-bnc-1
Physical specs
Material		Brass
Plating		Nickel
Plastic bush		plastic
Dimensions (height x diameter)	mm	27x5.5
Weight	kg	0.01
Electrical parameters
Impedance	ohm	75
Frequency range	GHz	0-3
VSWR at 1 GHz		<1.1
Return loss at 1GHz	dB	>30
Screening efficiency at 1GHz	dB	>100
Dongbei manufacture and supply super designed F Connector, BNC Connector. This BNC connector/adapter has been designed to ensure watertightness (after crimping). During compression of the connector a plastic bush is tightly pressed against the sheath of the cable (by putting on cone-shaped brass bush). The plastic material It is UV-proof, and ensures stable physical parameters in very wide temperature range. The metal parts of the connector are made of nickel-plated brass and are corrosion-proof. The way of crimping ensures high mechanical strength, watertightness, and stability of parameters. The compression should be made with the crimping tool:
