New Standards, New Look, New Features
12-24V DC Fiber Optical Sensor , Two Output(NPN)Type
F&C Sensing Technology has board selections of sensors. We have 140 models in stock and can deliver to our customer at any time.
FF-302 High Performance Fiber Amplifier have two output(NPN Type).can detect different kind product at the same time.Meanwhile, F&C Sensing Technology also have high quality Fiber Tube match with this great amplifier
Feature:
1.Fastest Response Fiber Amplifier. Response time:16us
2.Longest Detection Distance. Detection Distance can be up to 20m
3.Triggering Delay Time Adjustable.
4.Excellent Anti-interference ability.
5.FF-302 two-way Output Fiber Amplifier For Option
6.Easy setting. Customer can set optical fiber amplifier themselves based on actual detecting distance.
7.Can be connected to 16 pieces of FF-30 16us sensor at same time.
8.Can detect high brightness object.
9.Performance is stable under dusty environment.
10Variety of optical fiber tuber for option
Specification for F&C FF-302 two output Fiber optical amplifier with CE
Output Mode |
NPN Two-way Output |
Fiber Amplifier Model |
FF-302 |
Operating Voltage |
12~24VDC |
Power Consumption |
Less than 45mA at 24V |
Short Circuit Protection |
Yes |
Working Indicator |
Red Led |
Digital Display |
4 bit green&4 bit red LCD Display |
Sensitivity Distance Setting |
Auto&Manual adjustment |
Responsing Time |
16us/70us/250us/2ms/8ms |
Timer Function |
ON Delay Time/OFF Delay timer, Adjustable valid or invalid(Regular time:1ms,5ms,10ms,20ms,40ms,100ms,500ms,1000ms) |
Timer Ajustable Time |
0.1ms~9s |
Input Setting Method |
Auto teach/test/sync |
Operating Temperature |
-25~55℃ |
Operating Humidity |
35~85% |
Storage Temperature |
-40~70℃ |
Storage Humidity |
35~85% |
Shockproof |
Frequency 10~150HZ double amplitude of 0.75mm , for 2hrs each XYZ direction |
Waterproof Grade |
IP50 |
Material |
ABS/PC |
Weight |
65g |
Our Services
1.Prompt reply to our customer, we have to reply all the email within 24hrs
2.Provide free replacement if there is any quality problem with our product.
3. Accept OEM Order, Ship the product with your logo.
Packaging & Shipping
We will ship our product aboard with standard export package.
For small Qty, We will Ship our product to you by express.
For mass production , We will ship our product to you by Air or sea.
Company Information
F&C Sensing Technology is founded in Taiwan in 1993. Establish its Dongguan factory in 2006 and move its factory to Changsha in 2013.
F&C Sensing Technology is a leading sensor supplier in China .Our product has been sold to all over the world.Its products cover 14 series and 3000 specification.
Our main product include Fiber Optic Sensor, Fiber Tube, Fiber Focus Lens, Proximity Switch, Photoelectric switch,Label Sensor, Light Curtain, Laser Alignment, Pressure Sensor, Magnetic Switch, Connector, Laser Sensor, Color Sensor,Rail Power Supply, Solid State Relay.
F&C Technology has been making continuous breakthrough in new technology and new material application,. Our Target is “What you need can be found in F&C Sensing Technology”
Note
-------------------------------------------------------------------------------------
1. Customize for cable length, housing material and shape.
2. The above information is only reference.
Welcome to contact with me. I can be reached by Skype:lynn_liu123 and whatapp:+8613319542018
