Dongbei f to Rca Video Audio Splitter Plug Adapter
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DongBei | |
| Model Number | DB8063-f female to rca male connector | Type | Adapter | |
| Application | RF | Gender | Other, female to male |
Product Description
Specifications
f to rca video audio splitter plug adapter1.High quality
2.Best service
3.Competitive prices
4.18 years factory experience
Dongbei f to rca video audio splitter plug adapter
| Temperature Range | -40~+60°C | |
| Impedance | 75 Ω | |
| Frequency Range | DC~1GHz | |
| Working Voltage | 170V max(rms) | |
| Withstand Voltage | 500V rms(at sea level) | |
| Contact Resistance | Center Resistance : ≤ 10 mΩ | Outer Contact : ≤ 5 mΩ |
| Insulation Resistance | ≥ 1000 MΩ | |
| VSWR | Straight : ≤ 1.20 | Right Angle : ≤1.30 |
| Center Conductor Retention Force | ≥ 0.2N | |
| Durability (mating) | ≥ 500 cycles | |
>>>The connectors are for low power,quick connect/disconnect applications using a bayonet type coupling mechanism and can be interchangeable with the same-type connectors of abroad.They are widely used in connection of the RF coaxial-cables in electronic equipment and instuments.Characteristic impedance 50Ω,75Ω .
* We have various types connector and an professional ,experienced service team.
* Welcome to login our website check more products information.
Dongbei QC Team
Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
We highly appreciate your any enquiry by email, fax or instant message.
We will reply your email or fax within 12 hours.
Please fell free to call us at any time if there is any questions.
Transportation
All available shipping ways could be applied, by courier, air or sea.
Appointed shipping company or our own forwarders all could be used in shipment.
Full-way tracking the cargos for you before the goods arrive.
