TV Plug Adapter Right Angle Pal Male to f Female Connector
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | DongBei | |
| Model Number | DB8056-A | Type | Adapter | |
| Application | RF | Gender | Other, pal male to f female |
Product Description
Specifications
right angle pal male to f female adapter1.pal to f adapter
2.factory price rf connector
3.ROHS
4.18 years experience
TV plug adapter right angle pal male to f female connector
| Temperature Range | -40~+60°C | |
| Impedance | 75 Ω | |
| Frequency Range | DC~1GHz | |
| Working Voltage | 170V max(rms) | |
| Withstand Voltage | 500V rms(at sea level) | |
| Contact Resistance | Center Resistance : ≤ 10 mΩ | Outer Contact : ≤ 5 mΩ |
| Insulation Resistance | ≥ 1000 MΩ | |
| VSWR | Straight : ≤ 1.20 | Right Angle : ≤1.30 |
| Center Conductor Retention Force | ≥ 0.2N | |
| Durability (mating) | ≥ 500 cycles | |
*** The connectors are for low power,quick connect/disconnect applications using a bayonet type coupling mechanism and can be interchangeable with the same-type connectors of abroad.They are widely used in connection of the RF coaxial-cables in electronic equipment and instuments.Characteristic impedance 50Ω,75Ω .


* We have various types connector and an professional ,experienced service team.
* Welcome to login our website check more products information.
Dongbei QC Team
- Donbei QC team consists of professional people to ensure 100% products high quality.
Contact Us
- We highly appreciate your any enquiry by email, fax or instant message.
- We will reply your email or fax within 12 hours.
- Please fell free to call us at any time if there is any questions.
Transportation
- All available shipping ways could be applied, by courier, air or sea.
- Appointed shipping company or our own forwarders all could be used in shipment.
- Full-way tracking the cargos for you before the goods arrive.
