Factory Supply 30amp Automatic MPPT Battery Charge Controller
GENERAL DESCRIPTION:
This SC-MCA MPPT (maximum power point tracking) solar charge controller is a smart solar controller with automatic recognition function, smart charging and discharge function, three stages charging function to protect battery. It can increase 30%-60% efficiency than traditional PWM controller. It supports many kinds of batteries. It also has RS232 communication function. It is a most cost effective MPPT solar charge controller currently.
Contact: Kevin Chan
W.A./Wechat: +86 1392 727 2408
QQ: 2355801987 (For online training)
Skype: live:exp8_1 (video call arrangement requested)
PRODUCT FEATURES
____________________________________________________________________________________________
|
Max PV Input DC 170V |
12V/24V/48V System | Peak Efficiency Up to 99% |
||||
| LCD/LED Monitor | Charging Method MPPT |
RS232 Port | ||||
|
Software Online-Upgrade |
System AUTO-RECOGNITION |
Unlimited PARALLEL |
||||
BATTERY OPTIONS
_____________________________________________________________________________________________
+ |
+ | + | + | |||||
Sealed Lead |
GEL Battery | Vented Battery |
Ni-Cd Battery |
|||||
- |
- | - |
- |
|||||
| Default | Manual Switch | Manual Switch | Manual Switch |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS:
SC-MCA MPPT Solar Charge Controller Automatic Recognition Series | ||||||
SC-MCA Series |
15A | 20A | 25A | 30A | 40A | |
Charge Mode |
MPPT (maximum power point tracking) |
|||||
Charge Method |
3 stages: constant current, constant voltage, floating charge |
|||||
System Type |
12V/24V/48V |
Automatic recognition |
||||
MPPT Efficiency |
12V/24V/48V |
≥96.5% |
||||
INPUT CHARACTERISTICS | ||||||
|
MPPT working voltage range
|
12V System |
DC18V~DC72V |
||||
24V System |
DC34V~DC72V |
|||||
48V System |
DC65V~DC144V |
|||||
|
Low input voltage protection point
|
12V System |
DC16V |
||||
24V System |
DC30V |
|||||
48V System |
DC60V |
|||||
|
Low input voltage recovery point |
12V System |
DC22V |
||||
24V System |
DC34V |
|||||
48V System |
DC65V |
|||||
High input voltage protection point |
12/24/48V System |
DC90V/DC90V/DC180V |
||||
High input voltage recovery point |
12/24/48V System |
DC85V/DC85V/DC170V |
||||
|
Maximum PV Power
|
12V System (W) |
213W |
284W |
355W |
426W |
568W |
24V System (W) |
426W |
568W |
710W |
852W |
1136W |
|
48V System (W) |
852W |
1136W |
1420W |
1704W |
2272W |
|
CHARGE CHARACTERISTICS | ||||||
Battery Type (Default Gel Battery) |
12/24/48V System |
Sealed lead acid, Vented, Gel, NiCd battery |
||||
Rated Input Current |
12/24/48V System |
15A |
20A |
25A |
30A |
40A |
OUTPUT DISCHARGE CHARACTERISTICS | ||||||
Rated Output Current |
40A |
|||||
The Output Control |
On mode, Off mode |
|||||
Output Control Set Mode |
Controller button or PC software |
|||||
MECHANICAL CHARACTERISTICS | ||||||
PC (communication port) |
RS232 |
|||||
Size D x W x H(mm) |
220*161*91 |
|||||
N.W.(kgs) |
2.5 |
3 |
||||
G.W.(kgs) |
3 |
3.5 |
||||
The specification is only for reference, subject to change without without prior notice! | ||||||
PRODUCT PHOTOS
_____________________________________________________________________________________________
Founded in 2009, Foshan SC Power Technology Ltd. is a National Key Support High-Tech Enterprise which integrated with R&D, production and marketing of Solar Inverter, Solar MPPT Controller, Hybrid Inverter (inverter with controller) and related solar power system products.
OUR ADVANTAGES:
Rapid growing industry
We are factory
High spirit team
Master core technology
Fast response and quality service
Full set of self-developing tools convenient to modify custom settings
Full team support for sales and technical services
PRODUCTION ABILITY:
5000sets/month ( Inverter/Hybrid Inverter)
10000sets/month (MPPT Solar Charge Controller)
R & D:
OEM / ODM acceptable
Warmly welcome to inquiry & place orders and wish we have a win-win business cooperation.
FACTORY BUILDING & OFFICE BUILDING
FACTORY & OFFICE INNER VIEW
- Software upgrade service;
- Free provides of spare parts within warranty
- Online/Onsite training of installation, debugging, maintenance, reparation, etc.
- Consolidation Service( only peripherals of our products)
- Promotion Support
HIGH-SPIRIT SERVICE TEAM LEADERS:
John Mo DJ Pang Jack Bai
(General Engineer) (Product Manager) (Service Manager)
Plywood External Packaging External Corrugated Box Packaging
Pallet for fork-lift loading
Container Loading @ company yard
