Home Ups Inverter 1000w 2000w 3000w 4000w 5000w
home ups inverter 1000w 2000w 3000w 4000w 5000w
Welcome to SCP factory
This is Fiona Yang,i will show you details about our products and factory.
Quick Details
- Place of Origin: Guangdong, China (Mainland)
- Brand Name: SC POWER
- Model Number: SC-V 5KVA
- Output Power: 4000W
- Output Type: Single
- Size: 458*210*216 mm
- Weight: 20 kgs
- Input Voltage: 12V/24V
- Output Voltage: 110V/220V/230V/240V
- Type: DC/AC Inverters
- Output Frequency: 50Hz/60Hz
- Output Current: 110V/40A; 220V/20A
GENERAL DESCRIPTION
In DC/AC inversion mode, user can set these series of inverters to normal working mode or sleep mode;
in utility mode, it has Auto Voltage Regulation (AVR) function, utility charging function (AC first mode) and UPS function.
This multi-functional low frequency pure sine wave inverter SC-V series have advantages of stable quality, strong load-carrying ability and long service life.
They also can work in poor environment and widely be used in military, industry, home, UPS, EPS, energy system field etc.
ADVANTAGES
- Charging current: 1-50A (AC, Auto-detect safety charging current)
- LCD monitor: Big professional
- Transformer: Toroidal
- Low Noise: < 45db
- Consumption: 1~6W (sleep mode); <1A (working mode)
- Input voltage: 145Vac-275Vac; 73Vac-138Vac
|
P R O T E C T I O N |
♦ Short-circuit Protection |
||||||||||
| ♦ Low Voltage Protection |
|||||||||||
| ♦ Over Voltage Protection |
|||||||||||
| ♦ Overheat Protection |
|||||||||||
♦ Overload Protection |
|||||||||||
Battery Options
___________________________________________________________________________________________________
+ |
+ | + | + | |||||
Sealed Lead |
GEL Battery | Vented Battery |
Ni-Cd Battery |
|||||
- |
- | - |
- |
|||||
| Default | Manual Switch | Manual Switch | Manual Switch |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS
| SC-V Pure Sine Wave Inverter | ||||||||||
| Series | 1KVA | 1.5KVA | 2KVA | 3KVA | 4KVA | 5KVA | 6KVA | 8KVA | 10KVA | |
| Rated Output Power | 800W | 1200W | 1600W | 2400W | 3200W | 4000W | 4800W | 6400W | 8000W | |
| Battery Voltage (DC) | 12V/24V (Optional) | 24V/48V (Optional) | 48V/96V/192V (Optional) | |||||||
| General Parameter | ||||||||||
| Working Mode (Setting) | 1 | Utility first (AC first) battery standby mode | ||||||||
| 2 | Sleep mode,no utility,load's power higher than 5% of inverter rated output power. it will start to work automatically | |||||||||
| 3 | Battery first (DC first) utility standby UPS mode | |||||||||
| AC Input | Voltage | 220V ± 35% or 110V ± 35% (Optional) | ||||||||
| Frequency |
50Hz ± 3% or 60Hz ± 3% (Optional) | |||||||||
| AC Output | Voltage | 220V ± 3% or 230V ± 3% or 110V ± 3% (Optional) | ||||||||
| Frequency | 50Hz ± 0.5 or 60Hz ± 0.5 (Optional) | |||||||||
| Battery Charge | AC Charge Current | 1 - 50A adjustable | ||||||||
| Display Information | Input voltage, output voltage, output frequency, battery capacity, load condition, status information | |||||||||
| Overload Protection | >120% 1min, >130% 10s | |||||||||
| Power Consumption | Sleep Mode | 1 - 6W | ||||||||
| Normal Mode | <1A | |||||||||
| Conversion Efficiency | 85% - 92% | |||||||||
| Transfer Time | <4ms (AC to DC / DC to AC) | |||||||||
| Protection | Overload, Short-circuit, High-voltage input, Low-voltage input, Overheat | |||||||||
| Size: W*D*H (mm) | 418*208*193.2 | 458*210*216 | 542.5*294*240.7 | |||||||
| Net Weight (kgs) | 11 | 13 | 14 | 15 | 17 | 20 | 34 | 39 | 43 | |
| The specification is only for reference. Subject to change without prior notice | ||||||||||
COMPANY INFORMATION
Founded in 2009, Foshan SC Power Technology Ltd. is a National Key Support High-Tech Enterprise which integrated with R&D,production and marketing of Solar Inverter, Solar MPPT Controller, Hybrid Inverter (inverter with controller) and related solar power system products...
OUR ADVANTAGES:
We are factory
Master core technology
High spirit team
Rapid growing industry
PRODUCTION ABILITY:
5000sets/month ( Inverter/Hybrid Inverter)
10000sets/month (MPPT Solar Charge Controller)
R & D:
OEM / ODM acceptable
Warmly welcome to inquiry & place orders and wish we have a win-win business cooperation.
OUR SERVICE
___________________________________________________________________________________________________
- Software upgrade service;
- Free provides of spare parts within warranty
- Online/Onsite training of installation, debugging, maintenance, reparation, etc.
- Consolidation Service( only peripherals of our products)
- Promotion Support
PACKAGING & SHIPPING
___________________________________________________________________________________________________
| Packaging Details: | EPE foam + edge/corner protector + 7 layers corrugated board carton |
|---|---|
| Delivery Detail: | 7 days for samples; 25~35 days for bulk order |
_________________________________________________________________________________________________
F.A.Q.
Q1: What's the different between inverter and hybrid inverter?
A1: Inverter is without controller,while the hybrid inverter is with built-in MPPT solar controller.
Q2: How about the delivery time?
A2: 7-10 days for sample; mass orders depend on the order quantity.
Q3: What is the warranty
A3: One year .
Q4: How to install the inverter?
